Schneider Electric QOB330VH5237 Miniature Circuit Breaker 240V 30A
Schneider Electric
$792.00
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 3 pole QO circuit breaker is rated at 30A at 120/240VAC. This unit provides 22kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product includes ring terminals. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
- Mercury Free:
- Yes
- Circularity Profile:
- N/A
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
- Height:
- 76 mm
- Tightening Torque:
- 4.6-4.6 N.m
- Poles Description:
- 3P
- Mounting Mode:
- bolt-on
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Width:
- 57 mm
- Number Of Spaces Required:
- 3
- Electrical Connection:
- ring tongue
- Net Weight:
- 0.390 kg
- Toxic Heavy Metal Free:
- Yes
- Product Certifications:
- UL Listed || CSA
- Depth:
- 74 mm
- Product Or Component Type:
- miniature circuit-breaker
- Eu Rohs Directive:
- Compliant with Exemptions
- Breaking Capacity:
- 22 kA 120/240 V AC 50/60 Hz || 22 kA 240 V AC 50/60 Hz || 22 kA 120 V AC 50/60 Hz
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Sustainable Offer Status:
- Green Premium product
- [Ue] Rated Operational Voltage:
- 120/240 V AC || 240 V AC || 120 V AC
- Range Of Product:
- QO
- Rohs Exemption Information:
- Yes
- Awg Gauge:
- AWG 14...AWG 8 copper
- Halogen Content Performance:
- Halogen free product
- Circuit Breaker Type:
- standard
- Line Rated Current:
- 30 A
- Warranty:
- 18 months
- Circuit Breaker Application:
- HACR rated
- Ambient Air Temperature For Operation:
- 40 °C
