Schneider Electric QOU3801042 Miniature Circuit Breaker 240V 80A
SKU:
QOU3801042
UPC:
785901666868
MPN:
Condition:
New
Range Of Product:
QOU
Circuit Breaker Application:
HACR rated
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Awg Gauge:
AWG 12...AWG 2/0 aluminium/copper
Width:
3 in
Height:
4.45 in
Line Rated Current:
80 A
Product Certifications:
UL Listed || CSA || IEC
Halogen Content Performance:
Halogen free product
Mounting Mode:
unit mount
Eu Rohs Directive:
Compliant with Exemptions
Product Or Component Type:
miniature circuit-breaker
[Ue] Rated Operational Voltage:
120/240 V AC || 240 V AC || 120 V AC || 60 V DC
Tightening Torque:
45-45 lbf.in (AWG 12...AWG 2/0)
Electrical Connection:
slotted box lugs, line side || slotted box lugs, load side
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Rohs Exemption Information:
Yes
California Proposition 65:
WARNING: This product can expose you to chemicals including: Cadmium and cadmium compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
QOU miniature molded case circuit breakers are intended for use in residential and commercial applications. These circuit breakers are unit mount thermal magnetic circuit breakers. QOU breakers will...
