Schneider Electric

Schneider Electric QOUR2305283 Miniature Circuit Breaker 120/240V 35A

SKU:

QOUR2305283

UPC:

3606486146958

MPN:

Condition:

New

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Product Or Component Type:

miniature circuit-breaker

Product Certifications:

CSA || UL Listed || IEC

Height:

4.05 in

[Ue] Rated Operational Voltage:

120/240 V AC || 120 V AC || 48 V DC

Eu Rohs Directive:

Compliant with Exemptions

Sustainable Offer Status:

Green Premium product

Mercury Free:

Yes

Circuit Breaker Application:

HACR rated

Depth:

2.95 in

Electrical Connection:

ring tongue, line side || ring tongue, load side

Range Of Product:

QOU

Circuit Breaker Type:

standard

Line Rated Current:

30 A

Toxic Heavy Metal Free:

Yes

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Circularity Profile:

N/A

Halogen Content Performance:

Halogen free product

Warranty:

18 months

Mounting Mode:

unit mount

Rohs Exemption Information:

Yes

Width:

1.5 in

California Proposition 65:

WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov

Tightening Torque:

45-45 lbf.in (AWG 14...AWG 2)

Awg Gauge:

AWG 14...AWG 2 aluminium/copper

Brochure:

View

Catalog:

View

Datasheet:

View
