Schneider Electric RSL1AB4BD Slim Relay 1C/O 6A 24 Vdc

(No reviews yet) Write a Review

Write a Review

Schneider Electric RSL1AB4BD Slim Relay 1C/O 6A 24 Vdc

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

RSL1AB4BD

UPC:

3606480077975

MPN:

Condition:

New

Safety Reliability Data:

B10d = 60000

Minimum Switching Current:

100 mA

Operating Position:

any position

Contacts Type And Composition:

1 C/O

Status Led:

without

Load Current:

6 A 250 V AC 0.5 mm mounting distance

Width:

5 mm

Product Certifications:

CSA || UL || EAC

Maximum Switching Capacity:

1500 VA || 150 W

Depth:

18.5 mm

Circularity Profile:

ENVEOLI1405004EN

Sustainable Offer Status:

Green Premium product

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Vibration Resistance:

+/- 1 mm 10-55 Hz)IEC 60068-2-6

Device Short Name:

RSL

Maximum Switching Voltage:

277 V

Device Presentation:

complete product

Toxic Heavy Metal Free:

Yes

Minimum Switching Capacity:

120 mW

Mounting Support:

socket or PCB

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Control Type:

without push-button

Test Levels:

level A group mounting

[Ithe] Conventional Enclosed Thermal Current:

6 A -40-55 °C

Toxic Free:

Yes

Reach Free Of Svhc:

Yes

Net Weight:

0.0054 kg

Mercury Free:

Yes

Contacts Material:

silver alloy (AgSnO2)

Terminals Description Iso N°1:

(11-12-14)OC || (A1-A2)CO

Environmental Disclosure:

ENVPEP1405004EN

Height:

28 mm

Rohs Exemption Information:

Yes

Minimum Switching Voltage:

12 V

Average Resistance:

3390 Ohm at 23 °C +/- 15 %

[Ui] Rated Insulation Voltage:

250 V IEC || 277 V cUL

Protection Category:

RT III

Average Coil Consumption:

0.17 W

[Uc] Control Circuit Voltage:

24 V DC

China Rohs Regulation:

X

Product Or Component Type:

plug-in relay

Ambient Air Temperature For Operation:

-40-55 °C

Ip Degree Of Protection:

IP40 conforming to IEC 60529

Electrical Durability:

60000 cycles, 6 A at 250 V, AC-1 C/O

California Proposition 65:

WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other repr

Shape Of Pin:

flat (PCB type)

Operating Rate:

<= 360 cycles/hour under load || <= 18000 cycles/hour no-load

[Ie] Rated Operational Current:

6 A AC-1/DC-1)IEC/UL

Series Name:

slim interface relay

Operating Time:

5 ms reset || 12 ms

Contact Operation:

standard

Ambient Air Temperature For Storage:

-40-70 °C

Rated Operational Voltage Limits:

18...33.6 V DC

Range Of Product:

Harmony Electromechanical Relays

Phenolic Free Solution:

Yes

Drop-Out Voltage Threshold:

>= 0.05 Uc

Standards:

CSA C22.2 No 14 || IEC 61810-1 || UL 508

Mechanical Durability:

10000000 cycles

Dielectric Strength:

1000 V AC between contacts || 4000 V AC between coil and contact

Warranty:

18 months

Reach Regulation:

Free of Substances of Very High Concern above the threshold

Shock Resistance:

5 gn 11 ms) not operating IEC 60068-2-27 || 5 gn 11 ms) in operation IEC 60068-2-27

[Uimp] Rated Impulse Withstand Voltage:

6 kV IEC
