Schneider Electric RXG11B7 1Co 10A Relay +Ltb-Led 24Vac Pack of 10
Schneider Electric
$93.30
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
This Harmony RXG plug-in relay socket has a coil control voltage of 24V AC and has 1 changeover contact SPDT (single pole double throw) with a rating of 10A." "It has large choice of number of contacts for high rated current use." "It also offers lockable test button." "It helps to reduce the size of enclosures and increase machine reliability, you can mount nearly everywhere thanks to its 16mm width." "Workability for hard-wired logic automated systems to complement the functions of industrial programmable logic controllers (PLCs)." 0 0 0 0 0 0 0 0 0 0 0
- Product Certifications:
- CE || UL || EAC || CSA || DNV-GL
- Ip Degree Of Protection:
- IP40
- Maximum Switching Voltage:
- 250 V AC || 30 V DC
- Ambient Air Temperature For Storage:
- -40-85 °C
- Dielectric Strength:
- 1000 V AC between contacts with micro disconnection || 5000 V AC between coil and contact with reinforced insulation
- Safety Reliability Data:
- B10d = 100000
- Torque Value:
- 0.8 N.m
- Drop-Out Voltage Threshold:
- >= 0.3 Uc AC
- Resistance:
- 260 Ohm +/- 10 %
- Reach Free Of Svhc:
- Yes
- Control Type:
- lockable test button
- Local Signalling:
- flag
- Minimum Switching Capacity:
- 500 mW at 100 mA, 5 V DC
- [Ithe] Conventional Enclosed Thermal Current:
- 10 A -40-55 °C
- Insulation Resistance:
- 1000 MOhm at 500 V DC
- Device Short Name:
- RXG
- Ambient Air Temperature For Operation:
- -40-70 °C
- Toxic Heavy Metal Free:
- Yes
- Load Current:
- 10 A 250 V AC
- Mechanical Durability:
- 10000000 cycles
- Status Led:
- without
- Overvoltage Category:
- III
- Net Weight:
- 0.02 kg
- Protection Category:
- RT I
- Device Presentation:
- complete product
- Sustainable Offer Status:
- Green Premium product
- Rohs Exemption Information:
- Yes
- Circularity Profile:
- N/A
- Maximum Switching Capacity:
- 2500 VA
- Shock Resistance:
- 20 gn in operation || 100 gn not in operation
- Product Or Component Type:
- plug-in relay
- Operating Rate:
- <= 1800 cycles/hour under load || <= 18000 cycles/hour no-load
- [Ui] Rated Insulation Voltage:
- 250 V IEC || 300 V CSA || 300 V UL
- Relative Humidity:
- 10-85 %
- Contacts Material:
- silver alloy (AgSnO2In2O3)
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other repr
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- [Ie] Rated Operational Current:
- 10 A 30 V DC) UL || 10 A 30 V DC) IEC || 10 A 250 V AC) IEC || 10 A 250 V AC) UL
- Environmental Disclosure:
- ENVPEP1406006EN
- [Uc] Control Circuit Voltage:
- 24 V AC 50/60 Hz
- Colour Of Cover:
- standard
- Vibration Resistance:
- 3 gn +/- 0.75 mm 10-150 Hz)in operation || 5 gn +/- 0.75 mm 10-150 Hz)not in operation
- China Rohs Regulation:
- X
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Range Of Product:
- Harmony Electromechanical Relays
- Test Levels:
- level A group mounting
- Control Circuit Voltage Limits:
- 0.8...1.1 Uc AC
- Mercury Free:
- Yes
- Mounting Position:
- any position
- Electrical Durability:
- 100000 cycles NO resistive at 55 °C || 100000 cycles NC resistive at 55 °C
- Pollution Degree:
- 2
- Utilisation Coefficient:
- 0.2
- Average Consumption:
- 0.82 VA 60 Hz
- Contacts Type And Composition:
- 1 C/O
- Standards:
- CSA C22.2 No 14 || UL 508 || IEC 61810-1
- Series Name:
- interface relay
