Schneider Electric RXM2AB1FD Miniature Relay 2C/O 110Vdc Pack of 10
This Harmony RXM miniature plug-in relay has a coil control voltage of 110V DC and has 2 changeover contacts DPDT (double pole double throw) with a rating of 12A." "It has large choice of number of contacts for high rated current use with space-saving design." "It also offers one-step lockable test button and mechanical indicator for contact status." "It helps to reduce the size of enclosures and increase machine reliability, you can mount nearly everywhere." "The product is IP40 and has a transparent cover allowing operator to visually inspect the status of contacts." "Workability for hard-wired logic automated systems to complement the functions of industrial programmable logic controllers (PLCs)." 0 0 0 "It is a green premium product and conforms to international standard and certifications like IEC, CE, UL, CSA, EAC, Lloyd's, RoHS and REACH." "RXM Relay should be used with a RXZE socket (screw clamp, screw connector, push-in terminal). To protect against vibrations, plastic/metal clamp can be added to the socket. Protection modules and marking legend are also available." "It is sold in lots of 10 and reference includes relay only." 0 "The RXM plug-in relays are a series of industrial plug-in relays designed for both simple and complex automation systems and available with 2 CO (12A), 3 CO (10A), 4 CO (6A) contacts, 4 CO (3A) low level contacts." 0 0
- Maximum Switching Capacity:
- 3000 VA/336 W
- Standards:
- UL 508 || IEC 61810-1 || CSA C22.2 No 14
- Reset Time:
- 20 ms
- [Uc] Control Circuit Voltage:
- 110 V DC
- Test Levels:
- level A group mounting
- Load Current:
- 12 A 250 V AC || 12 A 28 V DC
- Product Certifications:
- UL || Lloyd's || CE || CSA || GOST || IECEE CB Scheme
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Warranty:
- 18 months
- Protection Category:
- RT I
- Average Coil Consumption:
- 0.9 W
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Average Resistance:
- 13440 Ohm 20 °C +/- 10 %
- Operating Rate:
- <= 1200 cycles/hour under load || <= 18000 cycles/hour no-load
- Ambient Air Temperature For Operation:
- -40-55 °C
- Contacts Type And Composition:
- 2 C/O
- Shape Of Pin:
- flat
- Operating Time:
- 20 ms
- Control Type:
- lockable test button
- Maximum Switching Voltage:
- 250 V IEC
- [Ie] Rated Operational Current:
- 12 A 28 V DC) NO IEC || 12 A 250 V AC) NO IEC || 6 A 28 V DC) NC IEC || 6 A 250 V AC) NC IEC || 12 A 28 V DC) UL || 12 A 277 V AC) UL
- [Ui] Rated Insulation Voltage:
- 250 V IEC || 300 V CSA || 300 V UL
- Sustainable Offer Status:
- Green Premium product
- Drop-Out Voltage Threshold:
- >= 0.1 Uc
- Device Short Name:
- RXM
- Operating Position:
- any position
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other repr
- Ip Degree Of Protection:
- IP40 conforming to IEC 60529
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Range Of Product:
- Harmony Electromechanical Relays
- Mercury Free:
- Yes
- Product Or Component Type:
- plug-in relay
- Minimum Switching Capacity:
- 170 mW 10 mA, 17 V
- Contacts Material:
- AgNi
- China Rohs Regulation:
- X
- Pollution Degree:
- 3
- Device Presentation:
- complete product
- Circularity Profile:
- ENVEOLI2106019EN
- Shock Resistance:
- 10 gnin operation || 30 gnnot operating
- Net Weight:
- 0.037 kg
- Rohs Exemption Information:
- Yes
- Environmental Disclosure:
- ENVPEP2106019EN
- Safety Reliability Data:
- B10d = 100000
- Vibration Resistance:
- 3 gn +/- 1 mm 10-150 Hz)5 cycles in operation || 5 gn +/- 1 mm 10-150 Hz)5 cycles not operating
- Reach Free Of Svhc:
- Yes
- Ambient Air Temperature For Storage:
- -40-85 °C
- Mechanical Durability:
- 10000000 cycles
- Dielectric Strength:
- 1300 V AC between contacts with micro disconnection || 2000 V AC between coil and contact with basic insulation || 2000 V AC between poles with basic insulation
- Toxic Heavy Metal Free:
- Yes
- Continuous Output Current:
- 0.416666666666667
- Utilisation Coefficient:
- 0.2
- [Uimp] Rated Impulse Withstand Voltage:
- 4 kV 1.2/50 µs
- Rated Operational Voltage Limits:
- 88...121 V DC
- Series Name:
- Miniature
- Status Led:
- without
- Electrical Durability:
- 100000 cycles resistive
