Schneider Electric S29390 Circuit Breaker Shunt Trip 24V Dc

Schneider Electric S29390 Circuit Breaker Shunt Trip 24V Dc

Schneider Electric
SKU:
S29390
|
UPC:
785901627579
Availability:
Contact us to confirm availability and lead times.
$717.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
The PowerPact H-, J-, and L-frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. H- and J-frame circuit breakers are available with either thermal-magnetic or Micrologic electronic trip units. L-frame circuit breakers are available with Micrologic electronic trip units only. Shunt Trip (MX). Trips the circuit breaker when the control voltage rises above 70% of its rated voltage. Impulse type ≥ 20 ms or maintained control signals. AC shunt trips are suitable for ground-fault protection when combined with a Class I ground-fault sensing element. Continuous duty rated coil.
Additional Information
Product Certifications:
CSA || UL Listed
Product Or Component Type:
shunt trip
Rated Voltage:
24-24 V DC
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Tightening Torque:
1.4-1.4 N.m 0.82-2.5 mm² (AWG 18...AWG 14)
Range Of Product:
PowerPact H || PowerPact J || PowerPact L
Mercury Free:
Yes
Rohs Exemption Information:
Yes
Warranty:
18 months
Eu Rohs Directive:
Compliant with Exemptions
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
