Schneider Electric SSM3A325P7 3P Ssr 25A@48-600Vac Zero,200-265Vac

(No reviews yet) Write a Review

Write a Review

Schneider Electric SSM3A325P7 3P Ssr 25A@48-600Vac Zero,200-265Vac

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

SSM3A325P7

UPC:

3.60649E+12

MPN:

Condition:

New

Output Switching Mode:

zero voltage switching

Solid State Output Type:

zero voltage switching

Circularity Profile:

ENVEOLI1508007EN

Ambient Air Temperature For Operation:

-20-60 °C

Environmental Disclosure:

ENVPEP1508007EN

Device Short Name:

SSM3

Switching Voltage:

10 V turn-off || 180 V turn-on

Ambient Air Temperature For Storage:

-40-100 °C

Line Rated Current:

25 A

Input Current Limits:

19-24 mA

Marking:

CSA || CE || EAC || UL

Standards:

UL 508 || IEC 60950-1 || CSA C22.2 No 14

Mercury Free:

Yes

Cos Phi:

0.5-0.5 (with maximum load)

Insulation Resistance:

1000 MOhm

Number Of Channels:

3

Load Current:

0.1-25 A

Connections - Terminals:

screw terminals 0.2...1.3 mm², AWG 24...AWG 16) input || screw terminals 1.3...5.3 mm², AWG 16...AWG 10) output

[Uc] Control Circuit Voltage:

180...280 V AC

Maximum Voltage Drop:

<1.35 V on-state

Mounting Support:

symmetrical DIN rail

Dv/Dt:

500 V/µs off-state at maximum voltage

Output Voltage:

48...600 V AC

Sustainable Offer Status:

Green Premium product

Maximum Leakage Current:

0.25 mA off-state

Rohs Exemption Information:

Yes

Range Of Product:

Harmony Solid State Relays

Product Certifications:

CSA || UL || EAC

Dielectric Strength:

4 kV AC for input/output || 4 kV AC for input or output to case

Pollution Degree:

2

Net Weight:

0.74 kg

Local Signalling:

for input status LED (green)

Tightening Torque:

0.6...0.7 N.m for input || 1.36...1.7 N.m for output

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Ip Degree Of Protection:

IP20

Maximum Horse Power Rating:

1 hp 40 °C 240 V AC || 2 hp 40 °C 380 V AC || 3 hp 40 °C 480 V AC

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Phase:

3 phase

Response Time:

30 ms (turn-off) || 20 ms (turn-on)

Maximum I²T For Fusing:

410 A².s for 10 ms at 50 Hz || 374 A².s for 8.3 ms at 60 Hz

Surge Current:

286 A 20 ms 50 Hz || 300 A 16.6 ms 60 Hz

Product Or Component Type:

solid state relay up to 30 A

China Rohs Regulation:

X

Overvoltage Category:

III

Capacitance Unbalance:

8 pF for input/output

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Absolute Maximum Voltage:

1100 V
