Schneider Electric STBACI1225K Analog C In 2Chbasic4-20Akit Conns,Base

Schneider Electric STBACI1225K Analog C In 2Chbasic4-20Akit Conns,Base

Schneider Electric
SKU:
STBACI1225K
|
UPC:
3.59586E+12
Availability:
Contact us to confirm availability and lead times.
$341.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
This product is part of the Modicon STB range, an offer of modular distributed I/O. This basic analogue input kit is an accessory kit of Programmable Logic Controllers (PLC) and Programmable Automation Controllers (PAC). It has 2 analogue inputs (current 4mA to 20mA) with 10bit resolution. This product is compatible with most major fieldbus networks. It is an analogue input kit with a rated supply voltage of 24V DC and a current consumption of 30mA at 5V DC for logic bus. The response time is 5ms. It is an IP20 rated product. Its dimensions are 128.3mm (width) x 70mm (depth) x 13.9mm (height). It is suitable for packaging, bottling, assembly, distribution, textile, printing and semiconductor machines applications. This product is certified by FM Class 1 Division 2, ATEX category 3G, CE, UL, CSA and C-Tick. This kit is suitable for use with mounting base STBXBA1000 and power distribution module STBPDT3100/3105. The kit includes STBXTS1100, 6-terminal screw type connector, STBXBA1000 base, STBXTS2100, 6-terminal spring clamp connector and STBACI1225 module. The Modicon STB distributed I/O solution is an open, modular input/output system that makes it possible to design automation islands managed by a master controller via a bus or communication network.
Additional Information
Cold Swapping:
yes
Update Time:
10 ms
Supply:
power distribution module
Shock Resistance:
30 gn 11 ms IEC 88 reference 2-27
[Us] Rated Supply Voltage:
24 V DC
Absolute Maximum Input:
25 mA/50 V DC
Integral Linearity:
+/- 0.2 %FS
Response Time:
5 ms
Temperature Drift:
+/-0.01 %/°C
Maximum Supply Current For Sensors:
100 mA per input channels
Analogue Input Type:
current 4...20 mA
Ambient Air Temperature For Operation:
32...140 °F without derating
Differential Linearity:
monotonic
China Rohs Regulation:
X
Mercury Free:
Yes
Ambient Air Temperature For Storage:
-40...185 °F without derating
Rohs Exemption Information:
Yes
Analogue Input Number:
2
Ambient Air Temperature For Operation:
0-60 °C
Operating Altitude:
<= 6561.68 ft (2000 m)
Overvoltage Category:
II
Vibration Resistance:
+/-0.35 mm 10-58 Hz || 3 gn 58-150 Hz 35 x 7.5 mm symmetrical DIN rail || 5 gn 58-150 Hz 35 x 15 mm symmetrical DIN rail
Hot Swapping Fallback:
no for basic NIMs
Insulation Between Channels And Sensor Bus:
30 V
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Range Of Product:
Modicon STB distributed I/O solution
Input Impedance:
<= 300 Ohm
Insulation Between Channels And Logic Bus:
1500 V for 1 minute
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Ambient Air Temperature For Storage:
-40-85 °C without derating
Width:
128.3 mm
Relative Humidity:
95-95 % 60-60 °C without condensation
Current Consumption:
30 mA 5 V DC logic bus
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Marking:
CE
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Analogue Input Resolution:
10 bits
Product Or Component Type:
basic analog input kit
Kit Composition:
STBXTS1100, 6-terminal screw type connector || STBXBA1000 base || STBXTS2100, 6-terminal spring clamp connector || STBACI1225 module
Data Format:
EN 61131-2 || IEC 61131-2
Status Led:
1 LED (Green) module status (RDY)
Ip Degree Of Protection:
IP20 conforming to IEC 61131-2 class 1
Absolute Accuracy Error:
+/- 0.5 % of full scale 25 °C
Warranty:
18 months
Height:
13.9 mm
Type Of Filter:
single low pass input filter 25 Hz
Depth:
70 mm
Pollution Degree:
2 IEC 60664-1
Addressing Requirement:
2 input words
Product Certifications:
C-tick || UL || CSA || FM Class 1 Division 2 || ATEX Cat 3G
Product Compatibility:
mounting base STBXBA1000 || power distribution module STBPDT3100/3105
