Schneider Electric TM5SD000 Dummy Module (No-Functional)
Schneider Electric
$20.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric TM5SD000 Dummy Module (No-Functional)
This product is part of the Modicon TM5 range, an offer of IP20 modular I/O systems. This dummy module is suitable for programmable logic controllers (PLC) and programmable automation controllers (PAC). It is an IP20 rated product. It is suitable for packaging, material working, material handling and machine control solution applications. This product is certified by CE, C-Tick, CULus, CSA and GOST-R. It meets IEC 61131-2, CSA C22.2 No 213, UL 508 and CSA C22.2 No 142 standards. It is compatible with Modicon M258 and Modicon LMC058 range of products such as logic controller and motion controller. It is suitable for DIN rail mount. This IP20 modular IO system offers a flexible and scalable configuration of expansions by direct connection with the Modicon controllers. Flexible and scalable, designed for complex machines.
- Environmental Disclosure:
- ENVPEP1511026EN
- Storage Altitude:
- 0-3000 m
- Ambient Air Temperature For Operation:
- -10-55 °C without derating horizontal installation) || -10-60 °C with derating factor horizontal installation) || -10-50 °C vertical installation)
- Range Compatibility:
- Modicon M258 || Modicon LMC058
- Toxic Heavy Metal Free:
- Yes
- Sustainable Offer Status:
- Green Premium product
- Product Compatibility:
- logic controller || motion controller
- Operating Altitude:
- 0...6561.68 ft (0...2000 m)
- Circularity Profile:
- ENVEOLI1511026EN
- Relative Humidity:
- 5-95 % without condensation
- Mercury Free:
- Yes
- Product Or Component Type:
- dummy module
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Electromagnetic Compatibility:
- electrostatic discharge immunity test, 4 kV on contact IEC 61000-4-2 || electrostatic discharge immunity test, 8 kV in air IEC 61000-4-2 || susceptibility to electromagnetic fields, 1 V/m 2...2.7 GHz IEC 61000-4-3 || susceptibility to electromagnetic
- Standards:
- CSA C22.2 No 213 || IEC 61131-2 || CSA C22.2 No 142 || UL 508
- Reach Free Of Svhc:
- Yes
- Pollution Degree:
- 2 IEC 60664
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Pvc Free:
- Yes
- China Rohs Regulation:
- X
- Ip Degree Of Protection:
- IP20IEC 61131-2
- Range Of Product:
- Modicon TM5
- Product Certifications:
- GOST-R || C-tick || CSA || cULus
- Marking:
- CE
- Rohs Exemption Information:
- Yes
- Shock Resistance:
- 15 gn 11 ms
- Vibration Resistance:
- 1 gn 8.4-150 Hz DIN rail || 3.5 mm 5-8.4 Hz DIN rail
- Ambient Air Temperature For Storage:
- -40-70 °C
- Warranty:
- 18 months
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Datasheet:
- View
