Schneider Electric

Schneider Electric TM7SPS1A Power Distribution Block 24Vdc-15W

SKU:

TM7SPS1A

UPC:

3.59586E+12

MPN:

Condition:

New

Vibration Resistance:

7.5 mm constant amplitude 2-8 Hz)IEC 60721-3-5 Class 5M3 || 2 gn constant acceleration 8-200 Hz)IEC 60721-3-5 Class 5M3 || 4 gn constant acceleration 200-500 Hz)IEC 60721-3-5 Class 5M3

Pvc Free:

Yes

Rohs Exemption Information:

Yes

Operating Position:

any position

China Rohs Regulation:

X

Ambient Air Temperature For Storage:

-25-85 °C

Disturbance Radiated/Conducted:

CISPR 11

Nominal Power:

15 W

Electrical Connection:

1 male + 1 female connectors M8 power supply) || 1 male + 1 female connectors M12 TM7 bus)

Electromagnetic Compatibility:

EN/IEC 61000-4-6

Operating Altitude:

0...6561.68 ft (0...2000 m)

Fixing Mode:

by 2 screws

Supply Circuit Type:

DC

Surge Withstand:

0.5 kV differential mode IEC 61000-4-5 || 1 kV common mode IEC 61000-4-5

Product Compatibility:

motion controller || logic controller

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Shock Resistance:

30 gn 11 ms IEC 60721-3-5 Class 5M3

Environmental Disclosure:

ENVPEP1409005EN

Toxic Heavy Metal Free:

Yes

Warranty:

18 months

Local Signalling:

for sensor/actuator power supply status 2 LEDs

Resistance To Fast Transients:

2 kV IEC 61000-4-4 power supply) || 1 kV IEC 61000-4-4 input/output) || 1 kV IEC 61000-4-4 shielded cable)

Storage Altitude:

0-3000 m

Product Certifications:

C-tick || ATEX II 3g EEx nA II T5 || GOST-R || cURus

Standards:

IEC 61131-2

Marking:

CE

Circularity Profile:

ENVEOLI1409005EN

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Relative Humidity:

5-95 % without condensation

Sustainable Offer Status:

Green Premium product

Range Compatibility:

Modicon LMC058 || Modicon M258

[Us] Rated Supply Voltage:

24 V

Resistance To Electromagnetic Fields:

10 V/m 0.08-2 Hz IEC 61000-4-3 || 1 V/m 2-2.7 Hz IEC 61000-4-3

Product Specific Application:

supply 24 V DC I/O modules and bus TM7

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Mercury Free:

Yes

Product Or Component Type:

power distribution module

Net Weight:

0.19 kg

Ambient Air Temperature For Operation:

-10-60 °C

Resistance To Electrostatic Discharge:

6 kV in contact IEC 61000-4-2 || 8 kV in air IEC 61000-4-2

Range Of Product:

Modicon TM7

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Catalog:

View

Datasheet:

View
