Schneider Electric

Schneider Electric VW3A3725 Communication Card Bacnet With Removable

SKU:

VW3A3725

UPC:

3.60648E+12

MPN:

Condition:

New

Electrical Connection:

screw terminal block 5-pin removable terminal block, BACnet MS/TP

Mercury Free:

Yes

Storage Altitude:

0-3048 m

Product Certifications:

BTL || CSA || UL 508 || UL 873

Transmission Support Medium:

2 twisted pairs

Range Of Product:

Altivar

Electromagnetic Compatibility:

EMC immunity IEC 61000-6-1 || EMC immunity level 2 IEC 60730-1 || electrostatic discharge level 3B IEC 61000-4-2 || radiated RF fields level 3A IEC 61000-4-3 || electrical fast transient/burst immunity test level 4B IEC 61000-4-4 || surge immunity te

Vibration Resistance:

1.5 mm 3-13 Hz) || 1 mm 13-23 Hz) || 2 gn 13-150 Hz)

Transmission Rate:

9.6, 19.2, 38.4, 76.8 kbit/s

Display Type:

1 LED error || 1 LED transmission activity || 1 LED reception activity (RX) || 1 LED module status

Range Compatibility:

Altivar Process Modular || Altivar Process ATV600

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Communication Service:

AV, BV, MSV BACnet MS/TP || COV notification

Operating Altitude:

0...6561.68 ft (0...2000 m)

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Shock Resistance:

15 gn 11 ms

Ambient Air Temperature For Operation:

-20-65 °C

Circularity Profile:

N/A

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Product Compatibility:

ATV600

Product Or Component Type:

communication module

Communication Network Type:

RS485

Environmental Disclosure:

ENVPEP2010018EN

Communication Port Protocol:

BACnet MS/TP

Rohs Exemption Information:

Yes

China Rohs Regulation:

X

Ip Degree Of Protection:

IP20

Relative Humidity:

5-95 % without condensation

Ambient Air Temperature For Storage:

-25-70 °C

Sustainable Offer Status:

Green Premium product

Net Weight:

0.035 kg

Brochure:

View

Catalog:

View

Datasheet:

View
