Schneider Electric VW3A7705 Braking Resistor 10 Ohm 1000W

(No reviews yet) Write a Review

Write a Review

Schneider Electric VW3A7705 Braking Resistor 10 Ohm 1000W

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

VW3A7705

UPC:

3.38912E+12

MPN:

Condition:

New

Average Power Available:

1 kW 50 °C || 1.15 kW 40 °C

Width:

240 mm

Protection Type:

thermal protection via drive or temperature control switch 120 °C

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Mercury Free:

Yes

Rohs Exemption Information:

Yes

Ambient Air Temperature For Operation:

0-50 °C

Range Of Product:

Altivar

China Rohs Regulation:

X

Reach Free Of Svhc:

Yes

Continuous Power:

1000 W

Net Weight:

11 kg

Ohmic Value:

10 Ohm

Height:

484 mm

Contact Resistance:

60 µOhm

Product Compatibility:

LXM32MC10N4 || LXM32MD85N4 || ATV312HD11M3 || ATV312HD15M3 || ATV61HD11M3X || ATV61HD37N4 || ATV61HD55Y || ATV61HD75Y || ATV61WD45N4 || ATV61WD45N4C || ATV71HD11M3X || ATV71HD37N4 || ATV71HD45Y || ATV71HD55Y || ATV71WD37N4

Reach Regulation:

Free of Substances of Very High Concern above the threshold

Ip Degree Of Protection:

IP20

Toxic Heavy Metal Free:

Yes

Depth:

301 mm

Electrical Connection:

M6 bar wire drive || terminal <= 2.5 mm² / AWG 14 temperature control switch

[Ue] Rated Operational Voltage:

24 V DC 0.1 A || 250 V AC 1 A

Ambient Air Temperature For Storage:

-25-70 °C

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Range Compatibility:

Altivar 312 || Lexium 32i || Lexium 52 || Lexium 32 || Altivar 61

Warranty:

18 months
