Schneider Electric XACB9211 Pushbutton Head Pack of 10
Schneider Electric
$110.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric XACB9211 Pushbutton Head Pack of 10
This white booted operator is a separate component for double insulated, XACB pendant control station. Its maximum operating travel is equal to 16mm. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP65.
- Electrical Shock Protection Class:
- class II IEC 61140
- Operator Additional Information:
- booted
- Toxic Heavy Metal Free:
- Yes
- Mercury Free:
- Yes
- China Rohs Regulation:
- X
- Ambient Air Temperature For Operation:
- -25-70 °C
- Range Of Product:
- Harmony XAC
- Rohs Exemption Information:
- Yes
- Vibration Resistance:
- 15 gn 10-500 Hz)IEC 60068-2-6
- Marking:
- unmarked
- Reach Free Of Svhc:
- Yes
- Shock Resistance:
- 100 gn IEC 60068-2-27
- Operating Travel:
- 16 mm
- Ik Degree Of Protection:
- IK08 IEC 62262
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other repr
- Cap/Operator Or Lens Colour:
- white
- Product Or Component Type:
- head for push-button
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Warranty:
- 18 months
- Ambient Air Temperature For Storage:
- -40-70 °C
- Standards:
- IEC 60947-5-1 || CSA C22.2 No 14
- Sale Per Indivisible Quantity:
- 10
- Ip Degree Of Protection:
- IP65 conforming to IEC 60529
- Net Weight:
- 0.005 kg
- Component Name:
- XACB
- Product Compatibility:
- XESD1191 || XESD1291 || XESD1181 || XESD1281
- Catalog:
- View
- Datasheet:
- View
