Schneider Electric

Schneider Electric XB4BVG6 121 V Led Pilot Light Bod

(No reviews yet) Write a Review

Write a Review

Schneider Electric

Schneider Electric XB4BVG6 121 V Led Pilot Light Bod

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

XB4BVG6

UPC:

3389110168273

MPN:

Condition:

New

Signalling Type:

steady

Nema Degree Of Protection:

NEMA 13 || NEMA 4X

Head Type:

standard

[Uimp] Rated Impulse Withstand Voltage:

4 kV IEC 60947-1

Resistance To Fast Transients:

2 kV IEC 61000-4-4

Rohs Exemption Information:

Yes

Shape Of Signaling Unit Head:

round

Ambient Air Temperature For Operation:

-40-70 °C

Net Weight:

0.08 kg

Resistance To Electromagnetic Fields:

10 V/m IEC 61000-4-3

Range Of Product:

Harmony XB4

Device Presentation:

complete product

[Us] Rated Supply Voltage:

110...120 V AC 50/60 Hz

Surge Withstand:

1 kV IEC 61000-4-5

Product Or Component Type:

pilot light

Product Certifications:

CSA || UL Listed

Ip Degree Of Protection:

IP66 IEC 60529 || IP67 || IP69 || IP69K

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

[Ui] Rated Insulation Voltage:

250 V 3)IEC 60947-1

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Depth:

54 mm

Sale Per Indivisible Quantity:

1

Bezel Material:

chromium plated metal

Electromagnetic Emission:

class B IEC 55011

Cap/Operator Or Lens Colour:

blue

Electrical Shock Protection Class:

class I IEC 60536

Mercury Free:

Yes

Sustainable Offer Status:

Green Premium product

Vibration Resistance:

5 gn 12-500 Hz)IEC 60068-2-6

Bulb Base:

integral LED

Environmental Disclosure:

ENVPEP2308026EN

Standards:

IEC 60947-1 || JIS C8201-5-1 || IEC 60947-5-4 || UL 508 || IEC 60947-5-5 || IEC 60947-5-1 || CSA C22.2 No 14 || JIS C8201-1

Light Source:

universal LED

Circularity Profile:

ENVEOLI2308026EN

Protective Treatment:

TH

China Rohs Regulation:

X

Supply Voltage Limits:

100-132 V AC

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Terminals Description Iso N°1:

(X1-X2)PL

Ik Degree Of Protection:

IK06 IEC 50102

Device Short Name:

XB4

Resistance To Electrostatic Discharge:

6 kV on contact (on metal parts) IEC 61000-4-2 || 8 kV in free air (in insulating parts) IEC 61000-4-2

Shock Resistance:

30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27

Service Life:

100000 h at rated voltage and 25 °C

Current Consumption:

14 mA

Warranty:

18 months

Resistance To High Pressure Washer:

7000000 Pa 55 °C 0.1 m

Operator Additional Information:

with plain lens

Connections - Terminals:

screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1 || screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end IEC 60947-1

Important Message:

A change in appearance may be noted on the product but does not affect its use in terms of function and safety. This makes it compatible with our Universal LED blocks

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Light Source Colour:

blue

Ambient Air Temperature For Storage:

-40-70 °C

Fixing Collar Material:

zamak

Mounting Diameter:

22 mm

Width:

30 mm

Height:

47 mm
