Schneider Electric XB4BW23B5 Metal Push-To-Test Pilot Light 24V Green

(No reviews yet) Write a Review

Write a Review

Schneider Electric XB4BW23B5 Metal Push-To-Test Pilot Light 24V Green

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

XB4BW23B5

UPC:

3606489420574

MPN:

Condition:

New

Ambient Air Temperature For Operation:

-40-70 °C

Depth:

55 mm

Light Source Colour:

green

Shock Resistance:

30 gn 18 ms) half sine wave acceleration IEC 60068-2-6 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-6

Eu Rohs Directive:

Compliant with Exemptions

Ip Degree Of Protection:

IP66 IEC 60536 || IP67 || IP69 || IP69K

Shape Of Signaling Unit Head:

round

Embedding Depth:

43 mm

Surge Withstand:

1 kV

Resistance To High Pressure Washer:

7000000 Pa 55 °C 0.1 m

Service Life:

1.5 year(s)

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Tightening Torque:

0.8-1.2 N.m IEC 60947-1

Connections - Terminals:

screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60068-2-27 || screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end IEC 60068-2-27

[Uimp] Rated Impulse Withstand Voltage:

6 kV IEC 60947-1

Mercury Free:

Yes

[Ui] Rated Insulation Voltage:

600 V 3)IEC 60947-1

Net Weight:

0.09 kg

Ik Degree Of Protection:

IK05 IEC 50102

Product Certifications:

GL || CSA || BV || UL Listed || LROS (Lloyds register of shipping) || DNV

Sale Per Indivisible Quantity:

1

Vibration Resistance:

5 gn 12-500 Hz)IEC 60068-2-6

Fixing Collar Material:

metal

Bezel Material:

metal

Device Short Name:

XB4

Signalling Type:

steady

[Us] Rated Supply Voltage:

24 V AC/DC 50/60 Hz

Product Or Component Type:

push-to-test pilot light

Light Source:

universal LED

Rohs Exemption Information:

Yes

Nema Degree Of Protection:

NEMA 13 IEC 60529 || NEMA 4X

Overvoltage Category:

class II IEC 60536

Current Consumption:

18 mA

Range Of Product:

Harmony XB4

Cap/Operator Or Lens Colour:

green

Mounting Diameter:

22 mm

Height:

42 mm

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Standards:

CSA C22.2 No 14 || IEC 60947-1 || IEC 60947-5-1 || IEC 60947-5-4 || GB 14048.5 || JIS C8201-5-1 || UL 508 || JIS C8201-1

Width:

30 mm

Important Message:

A change in appearance may be noted on the product but does not affect its use in terms of function and safety. This makes it compatible with our Universal LED blocks

Ambient Air Temperature For Storage:

-40-70 °C

Protective Treatment:

TH

China Rohs Regulation:

X

Catalog:

View

Datasheet:

View
