Schneider Electric XB6AF3B1B Green Illuminated Pushbut To N Diam 16 F
SKU:
XB6AF3B1B
UPC:
3389110763928
MPN:
Condition:
New
Shock Resistance:
30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Supply Voltage Limits:
6-30 V AC/DC
[Ie] Rated Operational Current:
3 A 120 V, AC-15, B300 EN/IEC 60947-5-1 || 1.5 A 240 V, AC-15, B300 EN/IEC 60947-5-1 || 0.1 A 250 V, DC-13, R300 EN/IEC 60947-5-1 || 0.22 A 125 V, DC-13, R300 EN/IEC 60947-5-1
Mounting Diameter:
16 mm
Rohs Exemption Information:
Yes
Resistance To Electromagnetic Fields:
10 V/m IEC 61000-4-3
Light Source:
LED
Bezel Material:
plastic
Positive Opening:
with EN/IEC 60947-5-1 appendix K
Warranty:
18 months
Terminals Description Iso N°1:
(13-14)NO
Operating Position:
any position
Device Short Name:
XB6
Product Certifications:
UL || CCC || GOST || CSA
Surge Withstand:
1 kV direct contact IEC 61000-4-5 || 2 kV in free air IEC 61000-4-5
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Short-Circuit Protection:
6 A cartridge fuse gG
Electrical Reliability:
λ = 10exp(-8) 5 V 1 mA with confidence level of 90 % IEC 60947-5-4
Environmental Disclosure:
ENVPEP1710010EN
Resistance To Fast Transients:
2 kV IEC 61000-4-4
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Protective Treatment:
TC
Sale Per Indivisible Quantity:
1
China Rohs Regulation:
X
Operating Travel:
1 mm NO changing electrical state) || 3.5 mm total travel)
Electrical Durability:
1000000 cycles, AC-15 230 V 3600 cyc/h 0.5 EN/IEC 60947-5-1 appendix C || 1000000 cycles, DC-13 230 V 3600 cyc/h 0.5 EN/IEC 60947-5-1 appendix C
Shape Of Signaling Unit Head:
round
[Ui] Rated Insulation Voltage:
250 V 3)EN/IEC 60947-1
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Net Weight:
0.022 kg
Electrical Shock Protection Class:
class II IEC 61140
Operator Profile:
green flush, unmarked
Signalling Type:
steady
Bulb Base:
integral LED
Contact Operation:
slow-break
Contacts Type And Composition:
1 NO
Range Of Product:
Harmony XB6
Ip Degree Of Protection:
IP65 IEC 60529
Contacts Material:
silver alloy (Ag/Ni)
Vibration Resistance:
+/- 3 mm 2-500 Hz)IEC 60068-2-6 || 5 gn 2-500 Hz)IEC 60068-2-6
Height:
18 mm
Width:
18 mm
Electromagnetic Emission:
class B IEC 55011
Ambient Air Temperature For Operation:
-25-70 °C
Mercury Free:
Yes
Resistance To Electrostatic Discharge:
6 kV on contact (on metal parts) IEC 61000-4-2 || 8 kV in free air (in insulating parts) IEC 61000-4-2
Type Of Operator:
latching
Connections - Terminals:
Faston connectors 2.8 x 0.5 mm
Depth:
57 mm
Product Or Component Type:
complete illuminated push-button
Nema Degree Of Protection:
NEMA 13 UL 50 || NEMA 4 UL 50 || NEMA 4X UL 50 || NEMA 13 CSA C22.2 No 94 || NEMA 4 CSA C22.2 No 94 || NEMA 4X CSA C22.2 No 94
Ambient Air Temperature For Storage:
-40-70 °C
Standards:
UL 508 || EN/IEC 60947-1 || JIS C 4520 || JIS C 852 || EN/IEC 60947-5-5 || CSA C22.2 No 14 || EN/IEC 60947-5-1
[Us] Rated Supply Voltage:
12...24 V AC/DC
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
This Harmony XB6 green, complete illuminated push button is part of the range diameter 16mm plastic, Harmony XB6 modular. It has a square head shape, with a flush spring return push and is supplied...
