Schneider Electric XENT1192 Contact Block
This product is part of the Harmony XAC range, an offer of pendant control stations for 22mm plastic signalling units. This single isolating block for control circuit. It has 3 normally closed contacts. It is an isolating block with a rated insulation voltage of 400V and a conventional enclosed thermal current of 10A. It is designed for front mounting with slow-break contact operation. It is furnished with screw clamp terminals for electrical connection. It offers mechanical durability of 1 million operating cycles. It weighs 0.05kg. It is suitable for industry and service sector, hoist and travelling cranes. It meets CSA C22.2 No 14, UL 508, EN/IEC 60947-5-1 and EN/IEC 60204-32 standards. It is compatible with the pendant control stations XACA. It is designed for mechanical handling, these highly robust pendant control stations comply with the safety requirements of IEC standards. They are not only simples and intuitive, but also very comfortable for the operator to use.
- [Ithe] Conventional Enclosed Thermal Current:
- 0.416666666666667
- Maximum Resistance Across Terminals:
- 25 MOhm
- Shock Resistance:
- 100 gn IEC 60068-2-27
- Contact Block Application:
- emergency stop push-button
- Warranty:
- 18 months
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Contacts Type And Composition:
- 3 NC
- Electrical Circuit Type:
- control circuit
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other repr
- Contact Code Designation:
- A600 AC-15, Ue = 240 V, Ie = 3 A IEC 60947-5-1 appendix A || A600 AC-15, Ue = 600 V, Ie = 1.2 A IEC 60947-5-1 appendix A || Q600 DC-13, Ue = 250 V, Ie = 0.27 A IEC 60947-5-1 appendix A || Q600 DC-13, Ue = 600 V, Ie = 0.1 A IEC 60947-5-1 appendix A
- Ambient Air Temperature For Operation:
- -25-70 °C
- Range Of Product:
- Harmony XAC
- Electrical Shock Protection Class:
- class II IEC 61140
- Contact Block Type:
- single
- Connections - Terminals:
- screw clamp terminals, 1 x 0.5...1 x 2.5 mm² without cable end || screw clamp terminals, 1 x 0.5...2 x 1.5 mm² with cable end
- Ambient Air Temperature For Storage:
- -40-70 °C
- Standards:
- CSA C22.2 No 14 || UL 508 || EN/IEC 60947-5-1 || EN/IEC 60204-32
- Short-Circuit Protection:
- 10 A fuse protection cartridge gG
- Rohs Exemption Information:
- Yes
- Product Or Component Type:
- isolating switch
- Component Name:
- XENT
- Mercury Free:
- Yes
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Mechanical Durability:
- 1000000 cycles
- Mounting Of Block:
- front mounting
- Product Compatibility:
- XACA
- Vibration Resistance:
- 15 gn 10-500 Hz)IEC 60068-2-6
- [Ui] Rated Insulation Voltage:
- 400 V 3)IEC 60947-1
- [Uimp] Rated Impulse Withstand Voltage:
- 6 kV IEC 60947-1
- Contact Operation:
- slow-break
- Operating Force:
- 14 N
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- China Rohs Regulation:
- X
- Net Weight:
- 0.05 kg
- Rated Operational Power In W:
- 40 W DC-13 1000000 cycles 60 cyc/mn 120 V 0.5 inductive IEC 60947-5-1 appendix C || 48 W DC-13 1000000 cycles 60 cyc/mn 48 V 0.5 inductive IEC 60947-5-1 appendix C || 65 W DC-13 1000000 cycles 60 cyc/mn 24 V 0.5 inductive IEC 60947-5-1 appendix C
