Schneider Electric XPSMCMCO0000PB Profibus Dp Diagnostics Exp. Screw Term

(No reviews yet) Write a Review

Write a Review

Schneider Electric XPSMCMCO0000PB Profibus Dp Diagnostics Exp. Screw Term

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

XPSMCMCO0000PB

UPC:

3606480748486

MPN:

Condition:

New

Connector Type:

female SUB-D 9

Method Of Access:

server

Device Short Name:

XPSMCM

Rohs Exemption Information:

Yes

Ambient Air Temperature For Operation:

-10-55 °C

Current Consumption:

0.125 mA

Communication Port Protocol:

Profibus DP

Overvoltage Category:

II

Pollution Degree:

2

Ip Degree Of Protection:

IP20

Connections - Terminals:

2 captive screw clamp terminals, removable terminal block

Product Certifications:

cULus || RCM || TÜV

Service Life:

20 year(s)

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Range Of Product:

Modicon MCM

Number Of Port:

1

Reach Free Of Svhc:

Yes

Transmission Rate:

500 kbit/s || 9.6 kbit/s || 19.2 kbit/s || 45.45 kbit/s || 93.75 kbit/s || 187.5 kbit/s || 1.5 kbit/s || 3 Mbit/s || 6 Mbit/s || 12 Mbit/s

Vibration Resistance:

+/-0.35 mm 10-55 Hz)IEC 61496-1

Environmental Disclosure:

ENVPEP1409010EN

[Us] Rated Supply Voltage:

24 V - 20...20 % DC

Shock Resistance:

10 gn 16 ms) 1000 shocks on each axis IEC 61496-1

Relative Humidity:

10-95 %

Cable Cross Section:

0.2-1.5 mm² - AWG 24...AWG 16 flexible without cable end || 0.2-2.5 mm² - AWG 24...AWG 14 flexible without cable end || 0.25-1 mm² - AWG 23...AWG 18 flexible with cable end, without bezel || 0.25-2.5 mm² - AWG 23...AWG 14 flexible with cable end, wit

Pvc Free:

Yes

Product Or Component Type:

non-safe communication module

China Rohs Regulation:

X

Insulation:

250 V AC between power supply and housing IEC 61800-5-1

Maximum Cable Distance Between Devices:

1000 m || 100 m || 1200 m || 400 m || 200 m

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Net Weight:

0.3 kg

Operating Altitude:

6561.68 ft (2000 m)

Width:

22.5 mm

Electromagnetic Compatibility:

electrostatic discharge immunity test - test level: 6 kV (on contact) conforming to IEC 61000-4-2 || electrostatic discharge immunity test - test level: 20 kV (on air) conforming to IEC 61000-4-2 || susceptibility to electromagnetic fields - test lev

Sustainable Offer Status:

Green Premium product

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Mercury Free:

Yes

Quality Labels:

CE

Local Signalling:

LED green PWR power ON || LED green RUN operating || LED red E IN internal error || LED red E EX external error || LED green/red STS communication status || LED green/red Mode connection state

Ambient Air Temperature For Storage:

-20-85 °C

Circularity Profile:

ENVEOLI1409010EN

Height:

99 mm

Reach Regulation:

Free of Substances of Very High Concern above the threshold

Depth:

114.5 mm

Range Compatibility:

Preventa XPSMCM

Power Dissipation In W:

3 W

Mounting Support:

omega 35 mm DIN rail EN 50022
