Schneider Electric XVUZ03 Xvu Direct Mounting Plate, 2 Pins
Schneider Electric
$20.00
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
This Harmony XVU fixing unit has 2-pins direct mounting. It has black color with a diameter of 60mm and a height of 100mm. It contains base unit. This black fixing unit is a mounting and fixing accessory for modular tower light. It allows users with easy installation via push-in terminals. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP65, making it ideal for operation in harsh environments. Simple modular design facilitates post installation servicing, modification and adaption of machines by non-specialists.
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Net Weight:
- 0.06 kg
- Ambient Air Temperature For Operation:
- -25-50 °C
- Environmental Disclosure:
- ENVPEP1403004EN
- Mounting Support:
- direct mounting
- Product Certifications:
- UL || CSA || CE
- Mercury Free:
- Yes
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Circularity Profile:
- ENVEOLI1403004EN
- Ip Degree Of Protection:
- IP65
- Component Name:
- XVU
- Product Or Component Type:
- modular tower light
- Pin Number:
- 2
- Ambient Air Temperature For Storage:
- -40-70 °C
- Product Compatibility:
- top AC body || top DC body || top swivel mounting support
- Length:
- 17-17 mm
- Connections - Terminals:
- push-in
- Accessory / Separate Part Type:
- mounting plate
- Rohs Exemption Information:
- Yes
- [Us] Rated Supply Voltage:
- 24 V AC/DC || 110...240 V AC
- Sustainable Offer Status:
- Green Premium product
- Mounting Diameter:
- 60 mm
- Housing Colour:
- black
- Range Of Product:
- Harmony XVU
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- China Rohs Regulation:
- X
- Material:
- PBT (polybutylene terephthalate) V-0 UL 94 || ABS (acrylonitrile butadiene-styrene) || PC (polycarbonate)
- Accessory / Separate Part Category:
- mounting and fixing accessory
- Catalog:
- View
- Datasheet:
- View
