Schneider Electric ZARB12W Base Station 12R Cable Gland
This Harmony eXLhoist / XAR black base station (receiver) has 12 relays outputs with 2 safety relays. This black base station (receiver) is designed as receiver for wireless remote control system. It is compatible with the remote control device ZART8L. It has 12 relay outputs with 2 safety relays and has wired connection cable gland. It is impact resistant, dust resistant, water resistant, corrosion resistant, and vibration resistant thanks to its IP65, making it ideal for operation in harsh (heavy) environments. It provides complete innovative crane operator control solutions to help improve machine and crane operator efficiency. Base station (receiver) has a unique identification code to allow the consistent and stable connection with its compatible remote control system.
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other repr
- [Us] Rated Supply Voltage:
- 24...240 V AC/DC
- Maximum Sensing Distance:
- 100 m in free field
- Service Life:
- 10 year(s)
- Net Weight:
- 1.45 kg
- Device Short Name:
- ZARB
- Vibration Resistance:
- 0.075 mm 10-55 Hz)
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Radio Agreement:
- ARIB || ICASA || RSS || SRRC || FCC || ANATEL
- Circularity Profile:
- ENVEOLI1404028EN
- Depth:
- 100 mm
- Product Certifications:
- KC || UL || C-tick || CE || EAC || CSA
- Fixing Mode:
- 4 holes
- Cable Entry:
- cable gland
- Number Of Channels:
- 40
- Relative Humidity:
- 0-97 %
- Mercury Free:
- Yes
- Electrical Durability:
- 100000 cycles
- Height:
- 305 mm
- Material:
- PC (polycarbonate)
- Relay Type:
- motion relay outputs 9 NO || auxiliary relay outputs 3 NO
- Electromagnetic Compatibility:
- resistance to electrostatic discharge - test level: 4 kV class B (on contact) conforming to IEC 61000-4-2 || resistance to electrostatic discharge - test level: 8 kV class B (in air) conforming to IEC 61000-4-2 || resistance to radiated electromagnet
- Nominal Output Current:
- 0.54 A 48 V AC IEC 60947-5-1
- Number Of Relays:
- 12
- Shock Resistance:
- 15 gn 11 ms
- Switching Capacity In Va:
- 5 VA DC || 26 VA AC
- Product Or Component Type:
- base station
- Maximum Switching Voltage:
- 240 V AC/DC + 20 %)
- Ip Degree Of Protection:
- IP65
- Provided Equipment:
- internal antenna
- Environmental Disclosure:
- ENVPEP1404028EN
- Maximum Switching Current:
- 6.8 mA
- Rohs Exemption Information:
- Yes
- Mechanical Durability:
- 1000000 cycles
- Product Specific Application:
- hoisting applications || material handling
- Ambient Air Temperature For Operation:
- -25-70 °C
- Ambient Air Temperature For Storage:
- -40-70 °C
- China Rohs Regulation:
- X
- Nema Degree Of Protection:
- NEMA 4
- Communication Network Type:
- wireless bluetooth low energy
- Pollution Degree:
- 3
- Width:
- 280 mm
- Transmission Frequency:
- 2.4 GHz
- Standards:
- IEC 61000-6-2
- Safety Outputs:
- 2 NC relay outputs
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Range Of Product:
- Harmony eXLhoist
