Schneider Electric ZB4BH053 Illuminated Push / Push H
Schneider Electric
$24.80
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric ZB4BH053 Illuminated Push / Push H
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
This Harmony XB4, illuminated flush orange button head for universal LED operates with a latched push-push mechanism. This illuminated button head for universal LED provides a versatile interface for controlling your machines. It is easily installed and replaced on compatible complete push button units and contact blocks via snap-fit assembly. It is clearly distinguishable visually at a distance thanks to illuminated, clear color and by touch due to flush element, minimizing errors in machine control. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66. It has a metal bezel, this makes it Ideal for applications requiring high impact and vibration resistance. It is designed to fit in a standard 22mm cutout, ensuring compatibility when installing in pre-existing machinery. Its wide range of operating temperatures from -40°C to 70°C allows versatility in usage of product. It provides high brightness for easy identification of function and operation mode, even in brightly lit environments.
- Range Of Product:
- Harmony XB4
- Electrical Shock Protection Class:
- class I IEC 60536
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Product Certifications:
- CSA || BV || UL Listed || LROS (Lloyds register of shipping) || GL || DNV
- Ip Degree Of Protection:
- IP66 IEC 60529 || IP67 || IP69 || IP69K
- Ambient Air Temperature For Storage:
- -40-70 °C
- Shock Resistance:
- 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
- Important Message:
- A change in appearance may be noted on the product but does not affect its use in terms of function and safety. This makes it compatible with our Universal LED blocks
- Resistance To High Pressure Washer:
- 7000000 Pa 55 °C 0.1 m
- Mercury Free:
- Yes
- Environmental Disclosure:
- ENVPEP1808008EN
- Protective Treatment:
- TH
- Reach Free Of Svhc:
- Yes
- Rohs Exemption Information:
- Yes
- Type Of Operator:
- push-push
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Overvoltage Category:
- class I IEC 60536
- Head Type:
- standard
- China Rohs Regulation:
- X
- Toxic Heavy Metal Free:
- Yes
- Standards:
- JIS C8201-5-1 || UL 508 || IEC 60947-5-5 || IEC 60947-5-1 || IEC 60947-1 || IEC 60947-5-4 || CSA C22.2 No 14 || JIS C8201-1
- Cad Overall Width:
- 29 mm
- Device Presentation:
- basic element
- Electrical Composition Code:
- M5 2 single front mounting integral LED || M6 2 single front mounting integral LED and transformer || M10 2 single front mounting integral LED
- Nema Degree Of Protection:
- NEMA 13 || NEMA 4X
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Shape Of Signaling Unit Head:
- round
- Product Compatibility:
- universal LED
- Bezel Material:
- chromium plated metal
- Vibration Resistance:
- 5 gn 2-500 Hz)IEC 60068-2-6
- Cad Overall Height:
- 29 mm
- Sale Per Indivisible Quantity:
- 1
- Net Weight:
- 0.026 kg
- Circularity Profile:
- ENVEOLI1808008EN
- Device Short Name:
- ZB4
- Product Or Component Type:
- head for illuminated push-button
- Operator Profile:
- orange flush, unmarked
- Ik Degree Of Protection:
- IK06 IEC 50102
- Cad Overall Depth:
- 30 mm
- Ambient Air Temperature For Operation:
- -40-70 °C
- Mechanical Durability:
- 500000 cycles
- Mounting Diameter:
- 22 mm
- Sustainable Offer Status:
- Green Premium product
- Warranty:
- 18 months
