Schneider Electric ZB4FV013 Flush Wh Projecting Pl Head Led

(No reviews yet) Write a Review

Write a Review

Schneider Electric

Schneider Electric ZB4FV013 Flush Wh Projecting Pl Head Led

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

ZB4FV013

UPC:

3606489582531

MPN:

Condition:

New

Ambient Air Temperature For Storage:

-40-70 °C

Bezel Material:

chromium plated metal

Shock Resistance:

30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27 || 25 gn 6 ms) 1000 shocks on each axis IEC 60068-2-27

Cad Overall Width:

36.6 mm

Reach Free Of Svhc:

Yes

Environmental Disclosure:

ENVPEP1808008EN

Protective Treatment:

TH

Cap/Operator Or Lens Colour:

white

Product Compatibility:

universal LED

Ambient Air Temperature For Operation:

-40-70 °C

Toxic Heavy Metal Free:

Yes

Sale Per Indivisible Quantity:

1

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Vibration Resistance:

5 gn 10-500 Hz)IEC 60068-2-6 || 2 mm peak to peak 2-10 Hz)IEC 60068-2-6

Shape Of Signaling Unit Head:

round

Operator Additional Information:

with plain lens

Important Message:

A change in appearance may be noted on the product but does not affect its use in terms of function and safety. This makes it compatible with our Universal LED blocks

Product Certifications:

UL Listed || CSA || CCC || EAC

Ik Degree Of Protection:

IK06 IEC 50102

Warranty:

18 months

Mercury Free:

Yes

Device Presentation:

basic element

Reach Regulation:

Free of Substances of Very High Concern above the threshold

China Rohs Regulation:

X

Mounting Diameter:

30.5 mm

Net Weight:

0.058 kg

Product Or Component Type:

head for pilot light

Resistance To High Pressure Washer:

7000000 Pa 55 °C 0.1 m

Range Of Product:

Harmony XB4

Cad Overall Height:

36.6 mm

Sustainable Offer Status:

Green Premium product

Overvoltage Category:

class I IEC 60536

Device Short Name:

ZB4F

Head Type:

built-in-flush

Rohs Exemption Information:

Yes

Ip Degree Of Protection:

IP66 IEC 60529 || IP67 IEC 60529 || IP69 IEC 60529 || IP69K ISO 20653 || Type 13 UL 50 E || Type 12 UL 50 E || Type 4 UL 50 E || Type 4X UL 50 E

Cad Overall Depth:

31 mm

Electrical Composition Code:

P1 front mounting integral LED || P2 front mounting integral LED and transformer

Standards:

IEC 60947-5-4 || IEC 60947-5-1 || UL 508 || CSA C22.2 No 14 || IEC 60947-1 || JIS C8201-5-1 || CE || JIS C8201-1

Circularity Profile:

ENVEOLI1808008EN
