Schneider Electric ZB4FV063 Flush Bl Projecting Pl Head Led

(No reviews yet) Write a Review

Write a Review

Schneider Electric

Schneider Electric ZB4FV063 Flush Bl Projecting Pl Head Led

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

ZB4FV063

UPC:

3606489582579

MPN:

Condition:

New

Important Message:

A change in appearance may be noted on the product but does not affect its use in terms of function and safety. This makes it compatible with our Universal LED blocks

Electrical Composition Code:

P1 front mounting integral LED || P2 front mounting integral LED and transformer

Sustainable Offer Status:

Green Premium product

Head Type:

built-in-flush

Product Or Component Type:

head for pilot light

Net Weight:

0.058 kg

Shock Resistance:

30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27 || 25 gn 6 ms) 1000 shocks on each axis IEC 60068-2-27

Reach Regulation:

Free of Substances of Very High Concern above the threshold

Ambient Air Temperature For Storage:

-40-70 °C

Standards:

EN/IEC 60947-5-4 || EN/IEC 60947-5-1 || UL 508 || CSA C22.2 No 14 || EN/IEC 60947-1 || JIS C8201-5-1 || CE || JIS C8201-1

Cad Overall Height:

36.6 mm

Rohs Exemption Information:

Yes

Protective Treatment:

TH

Ik Degree Of Protection:

IK06 IEC 50102

Sale Per Indivisible Quantity:

1

Toxic Heavy Metal Free:

Yes

Environmental Disclosure:

ENVPEP1808008EN

Cap/Operator Or Lens Colour:

blue

Operator Additional Information:

with plain lens

Cad Overall Depth:

31 mm

Vibration Resistance:

5 gn 10-500 Hz)IEC 60068-2-6 || 2 mm peak to peak 2-10 Hz)IEC 60068-2-6

Cad Overall Width:

36.6 mm

Shape Of Signaling Unit Head:

round

Device Presentation:

basic element

China Rohs Regulation:

X

Product Compatibility:

universal LED

Product Certifications:

UL Listed || CSA || CCC || EAC

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Mercury Free:

Yes

Reach Free Of Svhc:

Yes

Overvoltage Category:

class I IEC 60536

Range Of Product:

Harmony XB4

Device Short Name:

ZB4F

Warranty:

18 months

Bezel Material:

chromium plated metal

Ambient Air Temperature For Operation:

-40-70 °C

Resistance To High Pressure Washer:

7000000 Pa 55 °C 0.1 m

Mounting Diameter:

30.5 mm

Circularity Profile:

ENVEOLI1808008EN

Ip Degree Of Protection:

IP66 IEC 60529 || IP67 IEC 60529 || IP69 IEC 60529 || IP69K ISO 20653 || Type 13 UL 50 E || Type 12 UL 50 E || Type 4 UL 50 E || Type 4X UL 50 E
