Schneider Electric ZB5AW13 Illuminated Pushbutton He
This green projecting illuminated button head provides a versatile interface for controlling your machines. It is easily installed and replaced on compatible complete push button units and contact blocks via snap-fit assembly. It is clearly distinguishable visually at a distance thanks to clear color. It is also distinguishable by touch due to projecting element, minimizing errors in machine control. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66. It makes it ideal for operation in harsh environments.
- Product Certifications:
- CSA || DNV || GL || BV || LROS (Lloyds register of shipping) || UL Listed
- Protective Treatment:
- TC
- Cap/Operator Or Lens Colour:
- green
- Cad Overall Height:
- 29 mm
- Net Weight:
- 0.017 kg
- Shock Resistance:
- 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
- Operator Profile:
- green projecting, unmarked
- Cad Overall Depth:
- 32 mm
- Device Presentation:
- basic sub-assemblies
- Resistance To High Pressure Washer:
- 7000000 Pa 55 °C 0.1 m
- China Rohs Regulation:
- X
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Mounting Diameter:
- 22 mm
- Sale Per Indivisible Quantity:
- 1
- Overvoltage Category:
- class II IEC 60536
- Group Of Product:
- projected push BA9s
- Bezel Material:
- dark grey plastic
- Rohs Exemption Information:
- Yes
- Product Compatibility:
- BA 9s
- Station Name:
- XALD 1...5 cut-outs || XALK 2...5 cut-outs
- Electrical Composition Code:
- M7 6 single front mounting BA 9s || M8 6 single and double front mounting BA 9s || M9 2 single front mounting BA 9s and transformer || MF2 2 single front mounting BA 9s
- Standards:
- UL 508 || EN/IEC 60947-1 || EN/IEC 60947-5-4 || CSA C22.2 No 14 || EN/IEC 60947-5-1 || JIS C8201-5-1 || GB 14048.5 || JIS C8201-1
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Head Type:
- standard
- Cad Overall Width:
- 29 mm
- Vibration Resistance:
- 5 gn 2-500 Hz)IEC 60068-2-6
- Operator Additional Information:
- with plain lens
- Warranty:
- 18 months
- Product Or Component Type:
- head for illuminated push-button
- Range Of Product:
- Harmony XB5
- Ik Degree Of Protection:
- IK05 EN 50102
- Main Group:
- illum push-button
- Environmental Disclosure:
- ENVPEP1710010EN
- Ambient Air Temperature For Operation:
- -40-55 °C
- Sustainable Offer Status:
- Green Premium product
- Circularity Profile:
- ENVEOLI1710010EN
- Marking:
- unmarked
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Ambient Air Temperature For Storage:
- -40-70 °C
- Nema Degree Of Protection:
- NEMA 13 || NEMA 4X
- Ip Degree Of Protection:
- IP66 IEC 60529 || IP69 || IP69K
- Device Short Name:
- ZB5
- Type Of Operator:
- spring return
- Shape Of Signaling Unit Head:
- round
- Mechanical Durability:
- 10000000 cycles
- Mercury Free:
- Yes
