Schneider Electric ZB5AW163C0 Blue Proj Illum Pb Head For Integral
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
This illuminated button head for universal LED provides a versatile interface for controlling your machines. It is easily installed/replaced on compatible complete push-button units and contact blocks via snap-fit assembly. It is clearly distinguishable visually at a distance thanks to clear color and by touch due to projecting element, minimizing errors in machine control. It is imapct, dust, water and vibration resistant thanks to its IP66, making it ideal for operation in harsh environments.
- Mounting Diameter:
- 22 mm
- Cap/Operator Or Lens Colour:
- blue
- Bezel Material:
- plastic colour plated grey
- Sale Per Indivisible Quantity:
- 1
- Cad Overall Height:
- 29 mm
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Electrical Composition Code:
- M1 6 single front mounting integral LED || M2 6 single and double front mounting integral LED || M6 2 single front mounting integral LED and transformer || M10 2 single front mounting integral LED || MF1 2 single front mounting integral LED || MR1 2
- Product Compatibility:
- universal LED
- Cad Overall Depth:
- 33 mm
- Ambient Air Temperature For Operation:
- -40-70 °C
- Device Short Name:
- ZB5
- Group Of Product:
- proj push integral LED
- Nema Degree Of Protection:
- NEMA 13 || NEMA 4X
- Ik Degree Of Protection:
- IK05 EN 50102
- Net Weight:
- 0.018 kg
- Ip Degree Of Protection:
- IP66 IEC 60529
- Toxic Heavy Metal Free:
- Yes
- Cad Overall Width:
- 29 mm
- Resistance To High Pressure Washer:
- 7000000 Pa 55 °C 0.1 m
- Ambient Air Temperature For Storage:
- -40-70 °C
- Head Type:
- standard
- Shape Of Signaling Unit Head:
- round
- China Rohs Regulation:
- X
- Important Message:
- A change in appearance may be noted on the product but does not affect its use in terms of function and safety. This makes it compatible with our Universal LED blocks
- Rohs Exemption Information:
- Yes
- Shock Resistance:
- 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
- Range Of Product:
- Harmony XB5
- Operator Additional Information:
- with plain lens
- Protective Treatment:
- TC
- Station Name:
- XALD 1...5 cut-outs || XALK 2...5 cut-outs
- Standards:
- UL 508 || JIS C8201-5-1 || GB 14048.5 || CSA C22.2 No 14 || EN/IEC 60947-5-4 || EN/IEC 60947-1 || EN/IEC 60947-5-1 || JIS C8201-1
- Vibration Resistance:
- 5 gn 2-500 Hz)IEC 60068-2-6
- Product Certifications:
- BV || LROS (Lloyds register of shipping) || UL Listed || DNV || GL || CSA
- Main Group:
- illum push-button
- Product Or Component Type:
- head for illuminated push-button
- Operator Profile:
- blue projecting, unmarked
- Type Of Operator:
- spring return
- Mechanical Durability:
- 10000000 cycles
- Marking:
- unmarked
- Device Presentation:
- basic sub-assemblies
- Reach Free Of Svhc:
- Yes
- Mercury Free:
- Yes
- Overvoltage Category:
- class II IEC 60536
