Schneider Electric ZB5AW31 Illuminated Pushbutton He
Schneider Electric
$18.60
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
This white flush illuminated button head provides a versatile interface for controlling your machines. It is easily installed and replaced on compatible complete push button units and contact blocks via snap-fit assembly. It is very distinguishable visually at a distance thanks to illuminated, clear color and by touch due to flush element. It minimizes errors in machine control. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66. It makes it ideal for operation in harsh environments.
- Head Type:
- standard
- Nema Degree Of Protection:
- NEMA 13 || NEMA 4X
- Type Of Operator:
- spring return
- Mechanical Durability:
- 10000000 cycles
- Net Weight:
- 0.018 kg
- Bezel Material:
- dark grey plastic
- Ik Degree Of Protection:
- IK05 IEC 62262
- Standards:
- UL 508 || IEC 60947-5-4 || IEC 60947-1 || GB 14048.5 || JIS C8201-5-1 || IEC 60947-5-1 || CSA C22.2 No 14 || JIS C8201-1
- Cad Overall Depth:
- 32 mm
- Ambient Air Temperature For Storage:
- -40-70 °C
- Mercury Free:
- Yes
- Operator Additional Information:
- with plain lens
- Sustainable Offer Status:
- Green Premium product
- Device Presentation:
- basic sub-assemblies
- Operator Profile:
- white flush, unmarked
- Product Or Component Type:
- head for illuminated push-button
- Protective Treatment:
- TC
- Overvoltage Category:
- class II IEC 60536
- Sale Per Indivisible Quantity:
- 1
- Rohs Exemption Information:
- Yes
- Electrical Composition Code:
- M7 6 single front mounting BA 9s || M8 6 single and double front mounting BA 9s || M9 2 single front mounting BA 9s and transformer || MF2 2 single front mounting BA 9s
- Product Certifications:
- DNV || UL Listed || GL || CSA || LROS (Lloyds register of shipping) || BV
- Warranty:
- 18 months
- Ip Degree Of Protection:
- IP66 IEC 60529 || IP67 || IP69 || IP69K
- Cad Overall Width:
- 29 mm
- Group Of Product:
- flush push BA9s
- Device Short Name:
- ZB5
- Cap/Operator Or Lens Colour:
- white
- Shock Resistance:
- 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
- Resistance To High Pressure Washer:
- 7000000 Pa 55 °C 0.1 m
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Circularity Profile:
- ENVEOLI1710010EN
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Marking:
- unmarked
- Environmental Disclosure:
- ENVPEP1710010EN
- Range Of Product:
- Harmony XB5
- Ambient Air Temperature For Operation:
- -40-55 °C
- Mounting Diameter:
- 22 mm
- Vibration Resistance:
- 5 gn 2-500 Hz)IEC 60068-2-6
- Cad Overall Height:
- 29 mm
- Product Compatibility:
- BA 9s
- Station Name:
- XALD 1...5 cut-outs || XALK 2...5 cut-outs
- China Rohs Regulation:
- X
- Shape Of Signaling Unit Head:
- round
- Main Group:
- illum push-button
