Schneider Electric ZB5AW363C0 Blue Flush Illum Pb Head For Intgrl Led

(No reviews yet) Write a Review

Write a Review

Schneider Electric ZB5AW363C0 Blue Flush Illum Pb Head For Intgrl Led

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

ZB5AW363C0

UPC:

3606489770129

MPN:

Condition:

New

Electrical Composition Code:

M1 6 single front mounting integral LED || M2 6 single and double front mounting integral LED || M6 2 single front mounting integral LED and transformer || M10 2 single front mounting integral LED || MF1 2 single front mounting integral LED || MR1 2

Main Group:

illum push-button

Reach Free Of Svhc:

Yes

Operator Profile:

blue flush, unmarked

Reach Regulation:

Free of Substances of Very High Concern above the threshold

Operator Additional Information:

with plain lens

Bezel Material:

plastic colour plated grey

Important Message:

A change in appearance may be noted on the product but does not affect its use in terms of function and safety. This makes it compatible with our Universal LED blocks

Nema Degree Of Protection:

NEMA 13 || NEMA 4X

Ambient Air Temperature For Operation:

-40-70 °C

Protective Treatment:

TC

Net Weight:

0.017 kg

Shape Of Signaling Unit Head:

round

Range Of Product:

Harmony XB5

Resistance To High Pressure Washer:

7000000 Pa 55 °C 0.1 m

Marking:

unmarked

Group Of Product:

flush push integral LED

Toxic Heavy Metal Free:

Yes

Vibration Resistance:

5 gn 2-500 Hz)IEC 60068-2-6

Mounting Diameter:

22 mm

Ambient Air Temperature For Storage:

-40-70 °C

Ik Degree Of Protection:

IK05 EN 50102

Rohs Exemption Information:

Yes

Mechanical Durability:

10000000 cycles

Device Short Name:

ZB5

Overvoltage Category:

class II IEC 60536

China Rohs Regulation:

X

Device Presentation:

basic sub-assemblies

Standards:

EN/IEC 60947-5-4 || JIS C8201-5-1 || CSA C22.2 No 14 || EN/IEC 60947-1 || EN/IEC 60947-5-1 || UL 508 || GB 14048.5 || JIS C8201-1

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Product Compatibility:

universal LED

Mercury Free:

Yes

Cad Overall Width:

29 mm

Cap/Operator Or Lens Colour:

blue

Ip Degree Of Protection:

IP66 IEC 60529 || IP67

Sale Per Indivisible Quantity:

1

Head Type:

standard

Shock Resistance:

30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27

Product Certifications:

LROS (Lloyds register of shipping) || DNV || GL || BV || CSA || UL Listed

Station Name:

XALD 1...5 cut-outs || XALK 2...5 cut-outs

Cad Overall Depth:

30 mm

Type Of Operator:

spring return

Cad Overall Height:

29 mm

Product Or Component Type:

head for illuminated push-button
