Schneider Electric ZB5FD305C0 Flsmntd Yellow Sel Sw Head 3Pos Stay Put
Schneider Electric
$28.62
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric ZB5FD305C0 Flsmntd Yellow Sel Sw Head 3Pos Stay Put
This 30 mm selector switch head provides an ergonomic interface for controlling your machine. It is easily installed and replaced on compatible complete selector switch units and contact blocks via snap-fit assembly. It is clearly distinguishable visually at a distance thanks to its clear color. It is vibration resistant, impact resistant, high pressure washer resistant and dust resistant thanks to its IP66 protection, making it ideal for operation in harsh environments.
- Net Weight:
- 0.031 kg
- Protective Treatment:
- TH
- Bezel Material:
- plastic colour plated grey
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Ik Degree Of Protection:
- IK03 IEC 50102
- Product Or Component Type:
- head for selector switch
- Ambient Air Temperature For Storage:
- -40-70 °C
- Head Type:
- built-in-flush
- Cad Overall Height:
- 37 mm
- Reach Free Of Svhc:
- Yes
- Product Certifications:
- BV || CSA || LROS (Lloyds register of shipping) || DNV || UL Listed || GL
- Standards:
- UL 508 || JIS C8201-5-1 || EN/IEC 60947-1 || EN/IEC 60947-5-4 || EN/IEC 60947-5-1 || CSA C22.2 No 14 || JIS C8201-1
- Rohs Exemption Information:
- Yes
- Mercury Free:
- Yes
- Electrical Composition Code:
- C3 6 single front mounting || C4 6 single and double front mounting || C5 5 single front mounting || C6 5 single and double front mounting || C7 4 single front mounting || C8 4 single and double front mounting || C11 3 single front mounting || SF1 3
- Shape Of Signaling Unit Head:
- round
- Operator Position Information:
- 3 positions +/- 45°
- Type Of Operator:
- stay put
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Cad Overall Depth:
- 46 mm
- Device Presentation:
- basic element
- Resistance To High Pressure Washer:
- 7000000 Pa 55 °C 0.1 m
- Ip Degree Of Protection:
- IP66 IEC 60529 || IP67 IEC 60529
- Mounting Diameter:
- 30.5 mm
- Toxic Heavy Metal Free:
- Yes
- Vibration Resistance:
- 5 gn 2-500 Hz)IEC 60068-2-6
- Operator Profile:
- yellow standard handle
- Sale Per Indivisible Quantity:
- 1
- Device Short Name:
- ZB5
- Mechanical Durability:
- 1000000 cycles
- Cad Overall Width:
- 37 mm
- China Rohs Regulation:
- X
- Nema Degree Of Protection:
- NEMA 13 || NEMA 4X
- Overvoltage Category:
- class II IEC 60536
- Range Of Product:
- Harmony XB5
- Shock Resistance:
- 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
- Ambient Air Temperature For Operation:
- -40-70 °C
- Datasheet:
- View
