Schneider Electric ZB5FD4 Flush Mounted Black Selector Switch Head
Schneider Electric
$29.70
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric ZB5FD4 Flush Mounted Black Selector Switch Head
This 30 mm selector switch head provides an ergonomic interface for controlling your machine. It comes with antimicrobial characteristics. It is easily installed and replaced on compatible complete selector switch units and contact blocks via snap-fit assembly. It is clearly distinguishable visually at a distance thanks to its clear color. It is vibration resistant, impact resistant, high pressure washer resistant and dust resistant thanks to its IP69, IP66 protection, making it ideal for operation in harsh environments.
- Environmental Disclosure:
- ENVPEP1710010EN
- Shock Resistance:
- 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
- Mechanical Durability:
- 1000000 cycles
- Cad Overall Depth:
- 46 mm
- Ambient Air Temperature For Storage:
- -40-70 °C
- Rohs Exemption Information:
- Yes
- China Rohs Regulation:
- X
- Cad Overall Width:
- 37 mm
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Ik Degree Of Protection:
- IK03 IEC 50102
- Type Of Operator:
- right to left spring return
- Range Of Product:
- Harmony XB5
- Vibration Resistance:
- 5 gn 2-500 Hz)IEC 60068-2-6
- Nema Degree Of Protection:
- NEMA 13 || NEMA 4X
- Product Or Component Type:
- head for selector switch
- Standards:
- UL 508 || JIS C8201-5-1 || IEC 60947-5-4 || CSA C22.2 No 14 || IEC 60947-5-1 || IEC 60947-1 || JIS C8201-1 || ISO 21702 || ISO 22196:2011
- Net Weight:
- 0.031 kg
- Resistance To High Pressure Washer:
- 7000000 Pa 55 °C 0.1 m
- Bezel Material:
- dark grey plastic
- Mercury Free:
- Yes
- Operator Position Information:
- 2 positions 90°
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Toxic Heavy Metal Free:
- Yes
- Sale Per Indivisible Quantity:
- 1
- Reach Free Of Svhc:
- Yes
- Device Presentation:
- basic element
- Electrical Composition Code:
- C3 6 single front mounting || C4 6 single and double front mounting || C5 5 single front mounting || C6 5 single and double front mounting || C7 4 single front mounting || C8 4 single and double front mounting || C11 3 single front mounting || C15 1
- Device Short Name:
- ZB5
- Cad Overall Height:
- 37 mm
- Protective Treatment:
- TH
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Shape Of Signaling Unit Head:
- round
- Ambient Air Temperature For Operation:
- -40-70 °C
- Overvoltage Category:
- class II IEC 60536
- Product Certifications:
- UL Listed || DNV || LROS (Lloyds register of shipping) || GL || CSA || BV
- Sustainable Offer Status:
- Green Premium product
- Head Type:
- built-in-flush
- Circularity Profile:
- ENVEOLI1710010EN
- Operator Profile:
- black standard handle
- Mounting Diameter:
- 30.5 mm
- Ip Degree Of Protection:
- IP66 IEC 60529 || IP67 IEC 60529 || IP69K || IP69
- Datasheet:
- View
