Schneider Electric ZB5FD404C0 Flmnt Red Sel Sw Head 2Pos Ret Rt-Lt
Schneider Electric
$24.55
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric ZB5FD404C0 Flmnt Red Sel Sw Head 2Pos Ret Rt-Lt
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
This 30 mm selector switch head provides an ergonomic interface for controlling your machine. It is easily installed and replaced on compatible complete selector switch units and contact blocks via snap-fit assembly. It is clearly distinguishable visually at a distance thanks to its clear color. It is vibration resistant, impact resistant, high pressure washer resistant and dust resistant thanks to its IP66 protection, making it ideal for operation in harsh environments.
- Vibration Resistance:
- 5 gn 2-500 Hz)IEC 60068-2-6
- Ik Degree Of Protection:
- IK03 IEC 50102
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Sale Per Indivisible Quantity:
- 1
- Standards:
- CSA C22.2 No 14 || EN/IEC 60947-1 || UL 508 || EN/IEC 60947-5-4 || JIS C8201-5-1 || EN/IEC 60947-5-1 || JIS C8201-1
- Cad Overall Width:
- 37 mm
- Type Of Operator:
- right to left spring return
- Protective Treatment:
- TH
- Ambient Air Temperature For Operation:
- -40-70 °C
- Rohs Exemption Information:
- Yes
- Ip Degree Of Protection:
- IP66 IEC 60529 || IP67 IEC 60529
- Product Or Component Type:
- head for selector switch
- Electrical Composition Code:
- C3 6 single front mounting || C4 6 single and double front mounting || C5 5 single front mounting || C6 5 single and double front mounting || C7 4 single front mounting || C8 4 single and double front mounting || C11 3 single front mounting || C15 1
- Head Type:
- built-in-flush
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Mercury Free:
- Yes
- Operator Position Information:
- 2 positions 90°
- Reach Free Of Svhc:
- Yes
- Shock Resistance:
- 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
- China Rohs Regulation:
- X
- Shape Of Signaling Unit Head:
- round
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Cad Overall Height:
- 37 mm
- Toxic Heavy Metal Free:
- Yes
- Overvoltage Category:
- class II IEC 60536
- Device Presentation:
- basic element
- Mounting Diameter:
- 30.5 mm
- Bezel Material:
- plastic colour plated grey
- Ambient Air Temperature For Storage:
- -40-70 °C
- Mechanical Durability:
- 1000000 cycles
- Cad Overall Depth:
- 46 mm
- Resistance To High Pressure Washer:
- 7000000 Pa 55 °C 0.1 m
- Range Of Product:
- Harmony XB5
- Device Short Name:
- ZB5
- Net Weight:
- 0.031 kg
- Nema Degree Of Protection:
- NEMA 13 || NEMA 4X
- Operator Profile:
- red standard handle
- Product Certifications:
- GL || LROS (Lloyds register of shipping) || BV || CSA || UL Listed || DNV
- Datasheet:
- View
