Schneider Electric ZB5FH013C0 Flush Mount White Flush Caps Illum Head
Schneider Electric
$34.65
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric ZB5FH013C0 Flush Mount White Flush Caps Illum Head
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
This 30.5mm head for illuminated push-button provides an ergonomic interface for controlling your machine. It is easily installed and replaced on compatible complete push-button units and contact blocks via snap-fit assembly. It is clearly distinguishable visually at a distance thanks to its clear color. It is vibration resistant, impact resistant, high pressure washer resistant and dust resistant thanks to its IP67, IP66 protection, making it ideal for operation in harsh environments.
- Warranty:
- 18 months
- China Rohs Regulation:
- X
- Product Or Component Type:
- head for illuminated push-button
- Operator Profile:
- white flush, unmarked
- Resistance To High Pressure Washer:
- 7000000 Pa 55 °C 0.1 m
- Product Certifications:
- UL Listed || CSA
- Head Type:
- built-in-flush
- Sale Per Indivisible Quantity:
- 1
- Ip Degree Of Protection:
- IP66 IEC 60529 || IP67 IEC 60529
- Net Weight:
- 0.03 kg
- Device Presentation:
- basic element
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Electrical Composition Code:
- C11 3 single front mounting || C15 1 single front mounting || SF1 3 single front mounting || C9 3 single front mounting
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Mechanical Durability:
- 500000 cycles
- Protective Treatment:
- TH
- Bezel Material:
- plastic colour plated grey
- Overvoltage Category:
- class II IEC 60536
- Shape Of Signaling Unit Head:
- round
- Rohs Exemption Information:
- Yes
- Shock Resistance:
- 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27 || 25 gn 6 ms) 1000 shocks on each axis IEC 60068-2-27
- Product Compatibility:
- universal LED
- Cad Overall Height:
- 37 mm
- Cad Overall Depth:
- 30 mm
- Toxic Heavy Metal Free:
- Yes
- Ambient Air Temperature For Operation:
- -40-70 °C
- Ambient Air Temperature For Storage:
- -40-70 °C
- Vibration Resistance:
- 5 gn 10-500 Hz)IEC 60068-2-6 || 2 mm peak to peak 2-10 Hz)IEC 60068-2-6
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Mercury Free:
- Yes
- Type Of Operator:
- push-push
- Mounting Diameter:
- 30.5 mm
- Important Message:
- A change in appearance may be noted on the product but does not affect its use in terms of function and safety. This makes it compatible with our Universal LED blocks
- Standards:
- UL 508 || EN/IEC 60947-5-4 || EN/IEC 60947-1 || JIS C8201-5-1 || EN/IEC 60947-5-1 || CSA C22.2 No 14 || JIS C8201-1
- Ik Degree Of Protection:
- IK03 IEC 50102
- Cad Overall Width:
- 37 mm
- Range Of Product:
- Harmony XB5
- Device Short Name:
- ZB5F
- Reach Free Of Svhc:
- Yes
