Schneider Electric

Schneider Electric ZB5FV033C0 Flsmntd Green Pilotlight Head-Int Led

(No reviews yet) Write a Review

Write a Review

Schneider Electric

Schneider Electric ZB5FV033C0 Flsmntd Green Pilotlight Head-Int Led

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

ZB5FV033C0

UPC:

3606489754396

MPN:

Condition:

New

Reach Regulation:

Free of Substances of Very High Concern above the threshold

Ik Degree Of Protection:

IK03 IEC 50102

Toxic Heavy Metal Free:

Yes

Overvoltage Category:

class II IEC 60536

Sale Per Indivisible Quantity:

1

Ip Degree Of Protection:

IP66 IEC 60529 || IP67

Shape Of Signaling Unit Head:

round

Cad Overall Height:

37 mm

China Rohs Regulation:

X

Reach Free Of Svhc:

Yes

Shock Resistance:

30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27

Product Or Component Type:

head for pilot light

Electrical Composition Code:

P1 front mounting integral LED || P2 front mounting integral LED and transformer || PF1 front mounting integral LED

Cad Overall Width:

37 mm

Bezel Material:

plastic colour plated grey

Product Compatibility:

universal LED

Mounting Diameter:

30.5 mm

Resistance To High Pressure Washer:

7000000 Pa 55 °C 0.1 m

Mercury Free:

Yes

Cad Overall Depth:

30 mm

Net Weight:

0.015 kg

Important Message:

A change in appearance may be noted on the product but does not affect its use in terms of function and safety. This makes it compatible with our Universal LED blocks

Protective Treatment:

TH

Device Short Name:

ZB5

Nema Degree Of Protection:

NEMA 13 || NEMA 4X

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Standards:

EN/IEC 60947-1 || EN/IEC 60947-5-4 || UL 508 || CSA C22.2 No 14 || EN/IEC 60947-5-1 || JIS C8201-5-1 || EN/IEC 60947-5-5 || JIS C8201-1

Operator Additional Information:

with plain lens

Vibration Resistance:

5 gn 2-500 Hz)IEC 60068-2-6

Rohs Exemption Information:

Yes

Head Type:

built-in-flush

Ambient Air Temperature For Storage:

-40-70 °C

Range Of Product:

Harmony XB5

Ambient Air Temperature For Operation:

-40-70 °C

Device Presentation:

basic element

Cap/Operator Or Lens Colour:

green

Datasheet:

View
