Schneider Electric ZB6DA1 Rectangular Pushbut To N Head Diam 16 Wh

Schneider Electric ZB6DA1 Rectangular Pushbut To N Head Diam 16 Wh

Schneider Electric
SKU:
ZB6DA1
|
UPC:
3389110775488
$14.40
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
This Harmony ZB6DA1 is a white rectangular flush push button head, spring return, unmarked. It is part of the range Harmony XB6 diameter 16mm monolithic plastic push buttons, switches, and pilot lights.
Additional Information
Ambient Air Temperature For Storage:
-40-70 °C
Toxic Heavy Metal Free:
Yes
Net Weight:
0.016 kg
Ambient Air Temperature For Operation:
-25-70 °C
Cad Overall Height:
18 mm
Sustainable Offer Status:
Green Premium product
Sale Per Indivisible Quantity:
1
Range Of Product:
Harmony XB6
China Rohs Regulation:
X
Mercury Free:
Yes
Vibration Resistance:
+/- 3 mm 2-500 Hz)IEC 60068-2-6 || 5 gn 2-500 Hz)IEC 60068-2-6
Mounting Diameter:
16 mm
Electrical Shock Protection Class:
class II IEC 61140
Device Short Name:
ZB6
Reach Regulation:
Free of Substances of Very High Concern above the threshold
Warranty:
18 months
Bezel Material:
plastic
Nema Degree Of Protection:
NEMA 13 UL 50 || NEMA 4 UL 50 || NEMA 4X UL 50 || NEMA 13 CSA C22.2 No 94 || NEMA 4 CSA C22.2 No 94 || NEMA 4X CSA C22.2 No 94
Operator Profile:
white flush, unmarked
Circularity Profile:
ENVEOLI1710010EN
Standards:
EN/IEC 60947-5-5 || EN/IEC 60947-5-1 || JIS C8201-5-1 || CSA C22.2 No 14 || EN/IEC 60947-1 || JIS C 852 || UL 508 || JIS C8201-1
Rohs Exemption Information:
Yes
Type Of Operator:
spring return
Protective Treatment:
TC
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Cad Overall Width:
24 mm
Shape Of Signaling Unit Head:
rectangular
Reach Free Of Svhc:
Yes
Shock Resistance:
30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Cad Overall Depth:
33 mm
Product Or Component Type:
head for non-illuminated push-button
Ip Degree Of Protection:
IP65 IEC 60529
Product Certifications:
UL || CSA || GOST || CCC
Environmental Disclosure:
ENVPEP1710010EN
California Proposition 65:
WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Catalog:
View
Datasheet:
View
