Schneider Electric ZBE101GEX Aex No Contact Block

SKU:

ZBE101GEX

UPC:

3606489486112

MPN:

Condition:

New

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Ambient Air Temperature For Operation:

-50-75 °C

Rohs Exemption Information:

Yes

Marking:

Ex db eb IIC Gb

China Rohs Regulation:

X

Operating Force:

3.962 N

Product Or Component Type:

contact block

Cad Overall Depth:

42.4 mm

Net Weight:

0.018 kg

Product Certifications:

cULus

Contact Operation:

standard

Mercury Free:

Yes

Device Short Name:

ZBE

Circularity Profile:

ENVEOLI1808008EN

Ambient Air Temperature For Storage:

-50-70 °C

Contacts Usage:

gas protected contact

Operating Travel:

1.657 mm engagement point) || 4.622 mm changing state point) || 4.452 mm total travel)

Environmental Disclosure:

ENVPEP1808008EN

California Proposition 65:

WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

[Ie] Rated Operational Current:

1.9 A 380 V, AC, A600 IEC 60947-5-1 || 3 A 240 V, AC, A600 IEC 60947-5-1 || 6 A 120 V, AC, A600 IEC 60947-5-1 || 0.27 A 250 V, DC, Q300 IEC 60947-5-1 || 0.55 A 125 V, DC, Q300 IEC 60947-5-1 || 2.87 A 24 V, DC, Q300 IEC 60947-5-1

[Ui] Rated Insulation Voltage:

415 V

[Ith] Conventional Free Air Thermal Current:

10 A IEC 60947-5-1

Positive Opening:

without

Sale Per Indivisible Quantity:

1

Mounting Of Block:

front mounting

Connections - Terminals:

screw clamp terminals, 2 x 1.5 mm² without cable end || screw clamp terminals, 1 x 2.5 mm² with cable end

Reach Free Of Svhc:

Yes

Toxic Heavy Metal Free:

Yes

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Contacts Type And Composition:

1 NO

Cad Overall Width:

38 mm

Standards:

EN/IEC 60079-7 || EN/IEC 60079-0 || EN/IEC 60079-1 || EN/IEC 60079-31 || UL 60079-31 || UL 60079-0 || CSA C22.2 No 213 || UL 60079-1 || ANSI/ISA 12.12.01

Sustainable Offer Status:

Green Premium product

Tightening Torque:

0.8-1.2 N.m IEC 60947-1

Range Of Product:

Harmony XB4

Mechanical Durability:

1000000 cycles

Reach Regulation:

Free of Substances of Very High Concern above the threshold

Environmental Characteristic:

hazardous location class I division 2

Protective Treatment:

TH

Contact Block Type:

single

Cad Overall Height:

10 mm
