SensoPart FT 55-RLH-NS-L4 Diffuse laser sensor
Sensopart
The SensoPart FT 55-RLH-NS-L4 Diffuse Laser Sensor is a compact photoelectric sensor designed for precision and reliability. Featuring a laser proximity switch with background suppression, it operates with a red light at 655 nm and offers an NPN switching output. The sensor is housed in a cube-shaped enclosure, ensuring durability with an IP69K and IP67 protection standard, making it suitable for harsh environments.
This sensor boasts a scanning distance range of 5 to 800 mm, providing flexibility for various applications. It connects via a 4-pin M12 plug, ensuring secure and easy installation. With a high switching frequency of 1000 Hz, it is ideal for fast-paced industrial settings.
The FT 55-RLH-NS-L4 is part of the F55 series, known for its compact dimensions of 50 x 50.1 x 23 mm. It operates efficiently within a temperature range of -20 to +60°C, making it versatile for different working conditions. The sensor's adjustment is facilitated by a potentiometer, allowing for precise control.
For more detailed information, you can access the datasheet, catalog, brochure, operating instructions, and CAD files through the provided links. Order Number: 623-11019.
- Sensor principle:
- Photoelectric diffuse sensor with Background Suppression
- Series:
- F55 (50 x 50,1 x 23 mm)
- Working distance min. [mm]:
- 5
- Working distance max. [mm]:
- 800
- Velocity [Hz]:
- 1000
- Adjustment:
- Potentiometer
- Light source:
- Laser, red (Class 1)
- Switching output:
- NPN
- Temperature range [°C]:
- -20 ... +60
- Connection type:
- Plug M12, 4-pin
- Enclosure rating:
- IP69K, IP 67
- Datasheet:
- View
- Catalog:
- View
- Brochure:
- View
- Operating Instructions:
- View
- CAD:
- View
