The SensoPart FE 55-RL-NS-L4 Through-beam Laser Sensor is a high-performance photoelectric sensor designed for precise detection over long distances. With a working range of 0 to 25 meters, this sensor is ideal for applications requiring reliable object detection. It features a red laser light source (Class 1) and operates with a switching output of NPN. The sensor is equipped with a teach-in adjustment for easy setup and configuration.
Built to withstand harsh environments, the FE 55-RL-NS-L4 boasts an IP69K and IP67 enclosure rating, ensuring protection against dust, water, and high-pressure cleaning. It operates efficiently within a temperature range of -20 to +60°C, making it suitable for various industrial settings. The sensor's compact design, part of the F55 series, measures 50 x 50.1 x 23 mm and connects via a 4-pin M12 plug.
For further technical details, you can access the datasheet, catalog, brochure, operating instructions, and CAD files through the provided links. This sensor is an excellent choice for those seeking a robust and versatile solution for their automation needs.
- Sensor principle:
- Photoelectric through-beam sensor (sender/receiver)
- Series:
- F55 (50 x 50,1 x 23 mm)
- Working distance min. [mm]:
- 0
- Working distance max. [mm]:
- 25000
- Velocity [Hz]:
- 3500
- Adjustment:
- Teach-in
- Light source:
- Laser, red (Class 1)
- Switching output:
- NPN
- Temperature range [°C]:
- -20 ... +60
- Connection type:
- Plug M12, 4-pin
- Enclosure rating:
- IP69K, IP 67
- Datasheet:
- View
- Catalog:
- View
- Brochure:
- View
- Operating Instructions:
- View
- CAD:
- View
- QN-QUOTE-REQUEST:
- true
