The SensoPart FGL 50-RK-50-PSM4 Fork Sensors are designed for precision and reliability in detecting small parts as tiny as 0.2 mm. With a fork width of 50 mm and utilizing red light technology, these sensors offer a high switching frequency of 2000 Hz, ensuring rapid and accurate detection. The robust metal plug connection features a 4-pin M8 design, providing durability and secure connectivity. Sensor adjustments are made easy with teach-in and control input options, allowing for seamless integration into various applications. The sensors also offer versatile mounting possibilities and can be configured for normally open (N.O.) or normally closed (N.C.) operation, making them adaptable to a wide range of industrial environments.
- Series:
- Optical fork
- Working distance min. [mm]:
- 0
- Working distance max. [mm]:
- 50
- Velocity [Hz]:
- 2000
- Adjustment:
- Teach-in
- Light source:
- LED, red
- Switching output:
- PNP
- Temperature range [°C]:
- -20 ... +60
- Connection type:
- Plug M8, 4-pin
- Enclosure rating:
- IP 67
- Datasheet:
- View
- Catalog:
- View
- Operating Instructions:
- View
- CAD:
- View
- QN-QUOTE-REQUEST:
- true
