SensoPart FGL 80-RK-50-PSM3 Fork sensors

SensoPart FGL 80-RK-50-PSM3 Fork sensors

Sensopart
SKU:
FGL80-RK-50-PS-M3
Availability:
Contact us to confirm availability and lead times.
$188.00
Condition:
New
Current Stock:
Description
The SensoPart FGL 80-RK-50-PSM3 Fork Sensors are designed with a robust plastic construction and feature an 80 mm fork width, making them ideal for precise small part detection as fine as 0.2 mm. Equipped with a red light source and a high-speed response rate of 2000 Hz, these sensors ensure accurate and reliable performance. The device includes a durable metal plug M8 3-pin connection, providing a secure and stable interface. Sensor adjustments are made easy with the teach-in function and control input, allowing for quick and efficient setup. With versatile mounting possibilities and the ability to switch between normally open (N.O.) and normally closed (N.C.) configurations, these fork sensors offer flexibility and adaptability for various applications.
Additional Information
Series:
Optical fork
Working distance min. [mm]:
0
Working distance max. [mm]:
80
Velocity [Hz]:
2000
Adjustment:
Teach-in
Light source:
LED, red
Switching output:
PNP
Temperature range [°C]:
-20 ... +60
Connection type:
Plug M8, 3-pin
Enclosure rating:
IP 67
Datasheet:
View
Catalog:
View
Operating Instructions:
View
CAD:
View
