The SensoPart FLE 18 W Through-beam Laser Sensor is designed for precision and reliability in industrial applications. With a maximum working distance of 50 meters, this sensor operates using a photoelectric through-beam principle, consisting of a sender and receiver. It features a PNP switching output with both normally open (N.O.) and normally closed (N.C.) configurations, ensuring versatile integration into various systems. The sensor is equipped with a 3-meter, 4-wire cable for easy connectivity.
This robust sensor operates at a velocity of 6000 Hz, providing rapid response times for high-speed applications. The laser light source is a red Class 1 laser, ensuring safe and efficient operation. The sensor's adjustment is facilitated by a potentiometer, allowing for precise calibration to suit specific needs.
Designed to withstand challenging environments, the FLE 18 W has an enclosure rating of IP65, offering protection against dust and water ingress. It functions effectively within a temperature range of -10 to +50°C, making it suitable for diverse industrial settings. For more detailed information, you can access the datasheet, catalog, and operating instructions through the provided links.
- Sensor principle:
- Photoelectric through-beam sensor (sender/receiver)
- Series:
- M18
- Working distance min. [mm]:
- 0
- Working distance max. [mm]:
- 50000
- Velocity [Hz]:
- 6000
- Adjustment:
- Potentiometer
- Light source:
- Laser, red (Class 1)
- Switching output:
- PNP
- Temperature range [°C]:
- -10 ... +50
- Connection type:
- Cable, 4-wire, 3 m
- Enclosure rating:
- IP65
- Datasheet:
- View
- Catalog:
- View
- Operating Instructions:
- View
