SensoPart FR 55-RL-NS-L4 Retro-reflective laser sensor
Sensopart
The SensoPart FR 55-RL-NS-L4 Retro-reflective Laser Sensor is a high-performance photoelectric sensor designed for precise detection tasks. With a working distance ranging from 0.3 to 12 meters, this sensor utilizes a red laser light source (Class 1) for accurate and reliable performance. It features a teach-in adjustment for easy setup and configuration, and operates with an NPN switching output. The sensor is built to withstand harsh environments, boasting an IP69K and IP67 enclosure rating, making it suitable for use in demanding industrial applications. It operates efficiently within a temperature range of -20 to +60°C and supports a velocity of up to 2000 Hz. The sensor is equipped with a 4-pin M12 plug connection for secure and straightforward installation. For more detailed information, you can access the datasheet, catalog, brochure, operating instructions, and CAD files through the provided links.
- Sensor principle:
- Photoelectric retro-reflective sensor
- Series:
- F55 (50 x 50,1 x 23 mm)
- Working distance min. [mm]:
- 300
- Working distance max. [mm]:
- 12000
- Velocity [Hz]:
- 2000
- Adjustment:
- Teach-in
- Light source:
- Laser, red (Class 1)
- Switching output:
- NPN
- Temperature range [°C]:
- -20 ... +60
- Connection type:
- Plug M12, 4-pin
- Enclosure rating:
- IP69K, IP 67
- Datasheet:
- View
- Catalog:
- View
- Brochure:
- View
- Operating Instructions:
- View
- CAD:
- View
- QN-QUOTE-REQUEST:
- true
