SensoPart FT 10-RLH-NS-KM4 Diffuse laser sensor with background suppression
Sensopart
The SensoPart FT 10-RLH-NS-KM4 is a high-performance diffuse laser sensor designed for precision detection with background suppression. It operates within a working distance range of 6 to 70 mm, utilizing a red laser light source classified as Class 1 for safe and efficient operation. The sensor features a compact design from the F10 series, measuring 21.1 x 14.6 x 8 mm, and offers a spot size of 1 x 3 mm for accurate detection. With a velocity of 1000 Hz, it ensures rapid response times, making it ideal for high-speed applications.
The sensor is equipped with a teach-in adjustment via control input, allowing for easy setup and configuration. It provides an NPN switching output and connects through a 200 mm pigtail with a 4-pin M8 connector, ensuring reliable and secure connections. Designed to withstand harsh environments, it boasts an IP 67 enclosure rating and operates within a temperature range of -20 to +50°C.
For further technical details, users can access the datasheet, catalog, brochure, operating instructions, and CAD files through the provided links. The SensoPart FT 10-RLH-NS-KM4 is an excellent choice for applications requiring precise and reliable photoelectric sensing with background suppression.
- Sensor principle:
- Photoelectric diffuse sensor with Background Suppression
- Spot size [mm]:
- 1 x 3
- Series:
- F10 (21,1 x 14,6 x 8 mm)
- Working distance min. [mm]:
- 6
- Working distance max. [mm]:
- 70
- Velocity [Hz]:
- 1000
- Adjustment:
- Control input
- Light source:
- Laser, red (Class 1)
- Switching output:
- NPN
- Temperature range [°C]:
- -20 ... +50
- Connection type:
- Pigtail, plug M8, 4-wire, 200 mm
- Enclosure rating:
- IP 67
- Datasheet:
- View
- Catalog:
- View
- Brochure:
- View
- Operating Instructions:
- View
- CAD:
- View
