SensoPart FT 12 R-PSL4 Photoelectric diffuse sensorackground suppression
Sensopart
The SensoPart FT 12 R-PSL4 is a high-performance photoelectric diffuse sensor with background suppression, designed for precise detection tasks. It features an adjustable scanning distance ranging from 1 to 300 mm, allowing for versatile application in various environments. The sensor operates with a red light at 660 nm, ensuring reliable performance. Installation is straightforward, thanks to the standard M12 metal thread, and the device includes a functional reserve indicator for added convenience. The sensor is equipped with a PNP normally open (N.O.) output and a 4-pin M12 plug, making it an ideal choice for seamless integration into existing systems.
- Sensor principle:
- Photoelectric diffuse sensor
- Spot size [mm]:
- 5 x 5
- Series:
- M12
- Working distance min. [mm]:
- 1
- Working distance max. [mm]:
- 300
- Velocity [Hz]:
- 1000
- Adjustment:
- Potentiometer
- Light source:
- LED, red
- Switching output:
- PNP
- Temperature range [°C]:
- -25 ... +55
- Connection type:
- Plug M12, 4-pin
- Enclosure rating:
- IP 67
- QN-QUOTE-REQUEST:
- true
- Datasheet:
- View
- Catalog:
- View
- Operating Instructions:
- View
