SensoPart FT 18-2 IDM-NS-L4 Photoelectric diffuse sensor
Sensopart
The SensoPart FT 18-2 IDM-NS-L4 Photoelectric Diffuse Sensor is engineered for precision and reliability in demanding industrial settings. It boasts a working distance range of 0 to 800 mm, housed in a durable metal threaded casing. Utilizing an infrared LED light source, this sensor ensures optimal performance across various environments. It features an NPN switching output and a secure metal plug M12 4-pin connection for efficient connectivity. Operating at a velocity of 1000 Hz, it is ideal for high-speed applications. With a temperature range of -25 to +55°C and an IP67 enclosure rating, it offers robust protection against harsh conditions. The sensor also includes a potentiometer for easy adjustments. Access comprehensive specifications and installation instructions via the provided datasheet, catalog, operating instructions, and CAD links.
- Sensor principle:
- Photoelectric diffuse sensor
- Series:
- M18
- Working distance min. [mm]:
- 0
- Working distance max. [mm]:
- 800
- Velocity [Hz]:
- 1000
- Adjustment:
- Potentiometer
- Light source:
- LED, infrared
- Switching output:
- NPN
- Temperature range [°C]:
- -25 ... +55
- Connection type:
- Metal plug M12, 4-pin
- Enclosure rating:
- IP 67
- Datasheet:
- View
- Catalog:
- View
- Operating Instructions:
- View
- CAD:
- View
