SensoPart FT 18-2 R-NS-K4 Photoelectric diffuse sensor
Sensopart
The SensoPart FT 18-2 R-NS-K4 is a robust photoelectric diffuse sensor engineered for precision and reliability in demanding environments. It features a working distance range of 0 to 400 mm and utilizes a red LED light source for accurate detection. With an NPN switching output and a rapid operating velocity of 1000 Hz, this sensor ensures quick response times. Installation is simplified with a 2-meter, 4-wire cable, and its IP 67 enclosure rating guarantees durability in harsh conditions. The sensor operates efficiently within a temperature range of -25 to +55°C, and its performance can be customized using an adjustable potentiometer. Comprehensive resources, including datasheets, catalogs, operating instructions, and CAD files, are available for further technical details.
- Sensor principle:
- Photoelectric diffuse sensor
- Series:
- M18
- Working distance min. [mm]:
- 0
- Working distance max. [mm]:
- 400
- Velocity [Hz]:
- 1000
- Adjustment:
- Potentiometer
- Light source:
- LED, red
- Switching output:
- NPN
- Temperature range [°C]:
- -25 ... +55
- Connection type:
- Cable, 4-wire, 2 m
- Enclosure rating:
- IP 67
- Datasheet:
- View
- Catalog:
- View
- Operating Instructions:
- View
- CAD:
- View
