SensoPart FT 25-R-PS-M4M Diffuse photoelectric proximity sensor
Sensopart
The SensoPart FT 25-R-PS-M4M is a high-performance diffuse photoelectric proximity sensor designed for precision and reliability. With a working distance ranging from 0 to 800 mm, this sensor utilizes a red LED light source and features a teach-in adjustment for easy setup. It operates with a PNP switching output and is equipped with a robust metal plug M8, 4-pin connection, ensuring secure and stable connectivity. The sensor is built to withstand harsh environments, boasting an IP69K enclosure rating and a temperature range of -20 to +60°C. Ideal for various industrial applications, the FT 25-R-PS-M4M offers a fast response time with a velocity of 1000 Hz. For more detailed information, you can access the datasheet, catalog, brochure, operating instructions, and CAD files through the provided links.
- Sensor principle:
- Photoelectric diffuse sensor
- Series:
- F25 (34 x 20 x 12 mm)
- Working distance min. [mm]:
- 0
- Working distance max. [mm]:
- 800
- Velocity [Hz]:
- 1000
- Adjustment:
- Teach-in
- Light source:
- LED, red
- Switching output:
- PNP
- Temperature range [°C]:
- -20 ... +60
- Connection type:
- Metal plug M8, 4-pin
- Enclosure rating:
- IP69K
- Datasheet:
- View
- Catalog:
- View
- Brochure:
- View
- Operating Instructions:
- View
- CAD:
- View
