SensoPart FT 25-RA-170-PSU-M4M Miniature distance sensor
Sensopart
The SensoPart FT 25-RA-170-PSU-M4M Miniature Distance Sensor is designed for precision measurement with a working range of 30 to 200 mm and a resolution of 0.68 mm. Utilizing red LED light and triangulation sensor principles, it offers reliable performance with a linearity of 2 mm. The sensor features a teach-in function and provides an analog voltage output ranging from 1 to 10 V. It is equipped with a PNP switching output, which can auto-detect PNP/NPN configurations, and includes one switching output. The sensor's robust cubic design (34 x 20 x 12 mm) is complemented by a metal plug M8, 4-pin connection, ensuring secure and stable connectivity. With an enclosure rating of IP67 and IP69K, it is suitable for harsh environments, operating efficiently within a temperature range of -20 to +60°C. The sensor's high velocity of 1000 Hz ensures rapid response times, while its temperature drift is minimal at 0.2 mm/K. For further technical details, datasheets, catalogs, brochures, operating instructions, and CAD files are available for download.
- Linearity [mm]:
- 2
- Sensor principle:
- Distance sensor with triangulation
- Series:
- F25 (34 x 20 x 12 mm)
- Working distance min. [mm]:
- 30
- Working distance max. [mm]:
- 200
- Velocity [Hz]:
- 1000
- Type:
- Cubic
- Light source:
- LED, red
- Switching output:
- PNP, PNP/NPN (auto detect)
- Amount of swithing outputs:
- 1
- Resolution [mm]:
- 0.68
- Repeatability [mm]:
- 1
- Temperature range [°C]:
- -20 ... +60
- Temperature drift [%]:
- 0,2 mm / K
- Measurement output:
- Analog (voltage)
- Connection type:
- Metal plug M8, 4-pin
- Enclosure rating:
- IP 67, IP69K
- Datasheet:
- View
- Catalog:
- View
- Brochure:
- View
- Operating Instructions:
- View
- CAD:
- View
