SensoPart FT 55B-RH-NS-K4 Photoelectric diffuse sensor with background suppression
Sensopart
The SensoPart FT 55B-RH-NS-K4 is a high-performance photoelectric diffuse sensor with advanced background suppression, designed for precise detection tasks. It operates within a working distance range of 3 to 800 mm, utilizing a red LED light source for reliable performance. The sensor features a potentiometer for easy adjustment and an NPN switching output, making it versatile for various applications. With a robust enclosure rating of IP69K and IP67, it is well-suited for harsh environments, ensuring durability and longevity. The sensor is equipped with a 3-meter, 4-wire cable for convenient connectivity. It operates efficiently within a temperature range of -20 to +60°C and boasts a high velocity of 600 Hz, making it ideal for fast-paced industrial settings. For more detailed information, you can access the datasheet, catalog, brochure, operating instructions, and CAD files through the provided links.
- Sensor principle:
- Photoelectric diffuse sensor with Background Suppression
- Series:
- F55 (50 x 50,1 x 23 mm)
- Working distance min. [mm]:
- 3
- Working distance max. [mm]:
- 800
- Velocity [Hz]:
- 600
- Adjustment:
- Potentiometer
- Light source:
- LED, red
- Switching output:
- NPN
- Temperature range [°C]:
- -20 ... +60
- Connection type:
- Cable, 4-wire, 3 m
- Enclosure rating:
- IP69K, IP 67
- Datasheet:
- View
- Catalog:
- View
- Brochure:
- View
- Operating Instructions:
- View
- CAD:
- View
- QN-QUOTE-REQUEST:
- true
