SMC CDQ2F63-150DCZ-M9PWZ CQ2 Z Series Compact Cylinder
SMC
$240.25
The SMC CDQ2F63-150DCZ-M9PWZ CQ2 Z Series Compact Cylinder is a versatile and efficient solution for your pneumatic needs. This compact cylinder is designed to save space with its streamlined body, making it ideal for applications where space is at a premium. The CQ2 Z Series now includes sizes 4, 6, and 10, expanding its lineup from 4 to 200.
This cylinder allows for the mounting of small auto switches on four surfaces, with two surfaces available for sizes 12 to 25, ensuring flexibility and ease of use. The design eliminates the projection of the auto switch, contributing to a cleaner and more efficient setup.
The CQ2 Z Series is also lighter, with a weight reduction of 5 to 13% compared to the existing CQ2 series, making it easier to handle and install. It includes added pivot brackets for double clevis and compact type foot brackets, and part numbers with rod end bracket and/or mounting bolt are available, eliminating the need to order a bracket separately for the applicable cylinder.
With the option to include an auto switch, the SMC CDQ2F63-150DCZ-M9PWZ offers enhanced functionality and adaptability, making it a reliable choice for a wide range of industrial applications.
- Built-in Magnet:
- Built-in Magnet
- Mounting Style:
- Rod Side Flange Style
- Type:
- Pneumatic
- Bore Size:
- Bore Size 63 mm
- Port Thread Type:
- Rc/M Thread
- Cylinder Stroke:
- Standard Stroke 150 mm
- Action:
- Double Acting
- Cushion:
- With Rubber Bumper
- Body Option:
- Standard (Rod End Female Thread)
- Auto Switch Mounting Groove:
- 4 Sides
- Auto Switch:
- 2-color Indicator, Solid State Auto Switch, Grommet, With Indicator Light, 3-wire (PNP), In-line, Lead Wire :5m, Apply Voltage :DC5V,12V,24V(DC4.5~28V)
- Number Of Auto Switches:
- 2 pcs. Or None
- Made To Order:
- Standard
