SMC CLK2GA40-75YA-B2-P3DWASC-X1604 CLK2G/CLK2P Series Clamp Cylinder With Lock With Magnetic Field Resistant Auto Switch Rod Mounting
SMC
$1,386.85
The SMC CLK2GA40-75YA-B2-P3DWASC-X1604 is a high-performance clamp cylinder from the CLK2G/CLK2P Series, designed to enhance operational efficiency in industrial applications. This innovative clamp cylinder features a single-directional lock, allowing it to maintain a clamped or unclamped state even when air supply pressure drops or residual pressure is released. Its magnetic field resistant auto switch rod mounting ensures reliable performance in challenging environments. Additionally, the built-in cushion valve and plug eliminate overhang from the tube cover, streamlining operations and reducing maintenance needs. Ideal for applications requiring precise and secure clamping, this clamp cylinder is engineered for durability and efficiency.
- Type:
- Built-In Standard Magnet Type With Magnetic Field Resistant Auto Switch
- Clevis Width:
- 16.5 mm
- Bore Size:
- Bore Size 40 mm
- Port Type:
- Rc
- Cylinder Stroke:
- Standard Stroke 75 mm
- Cylinder Stroke:
- Double Knuckle Joint M6 With Tap
- Option:
- None
- Locking Direction:
- Retraction Locking
- Port/Bypass Piping Position:
- Port Position:Left
- Switch Mounting Rod Position:
- Top/None
- Auto Switch:
- Magnetic Field Resistant 2-color Indicator, Solid State Auto Switch, With Pre-wired Connector M12-4 pin, With Indicator Light, 2-wire, In-line, Lead Wire :0.3m, Apply Voltage :DC24V
- Number Of Auto Switches:
- 2 pcs. Or None
- Made To Order:
- Unlock-Port Separate Piping Type
